YAW-300D Electronic concrete compressive strength testing machine
- T/T Credit Card
You May Like
-
YAW-300D 30Ton 300kN computer controlled brick cement electric motor compression testing equipment
-
YAW-100D 10Ton 100kN computer control brick cement electric motor compression testing machine
-
YAW-200G 20Ton 200KN Computerized Mortar Cement Concrete Cubes Pressure Testing Machine
-
YES 100ton-300ton Digital Display Brick Compression and Bending Test Equipment / Concrete Compressive Strength Test Machine
-
YES-2000 200Ton Digital Display Hydraulic Compressive Strength Tester
-
YES-2000 2000KN Digital Manual Screw Hydraulic Cube Compression Testing Machine
Product Details
| Brand Name | Hensgrand | Place of Origin | Shandong, China | |
| Model Number | YAW-100/ 200/ 300D | Power | Electronic |
Product Description
YAW-300D Electronic concrete compressive strength testing machine
Introduction:
This machine adopt Ac servo drive, precision reduction gears drives the ball screw, with high test accuracy, low noise. More used computer control, with constant test force, constant stress, test force keep and control mode. Can test cement compression and flexual performance.
Main Specs:
Max compression test force | 300kN |
Max flexual test force | 10kN |
Test force range | 2%~100%FS |
Test force accuracy | ≤±1% |
Load speed | 0.1~9.9KN/S |
Displacement indicate error | ±1% |
Displacement resolution | 0.01mm |
Displacement speed adjust | 0.01~50mm/min |
Control and deal mode | Computer constant control and auto dealing |
Effective test width | 230mm |
Space between upper and lower | 200mm (optional) |
Effective compression space | 50mm |
Compression plate size | 140mm |
Machine size | 800×385×1490mm |
Power supply | 220V,50Hz,1500W |
YES-2000 YAW-2000D YES-300 YAW-300D
