YAW-300G 300KN Computer Closed-loop Control Cement Compression Testing Machine,concrete ,brick Testing Apparatus
1. Application :
Compressive Strength Testing machine is mainly used for the test brick, stone, cement, concrete and other materials, the compressive strength test, but also Compressive properties of other materials used for testing.
This machine is specially designed for the customers group. It can use in the above condition: strict loading progress, special control modulus, frequent space adjustment and bad enviroment.
2. Feature :
1. Computer closed-loop control, servo motor load, electric testing,digital display
2. Peak value holding, automatic saving amd printing
3. Automatically check all the related history record according to the test condition, test date and test data.
4. Automatic overload protection stop When the load more than full range 2% to 5%
3. Technical parameter :
Model | YAW-300G |
Max rupture testing force(kN) | 300/10 |
Test class | 1class or 0.5 class |
Range of testing force | 2%-100%FS |
Relative error of tesing indicating value | Better than ≤±1%/0.5 |
Control way | Computer |
Load way | Servo motor closed-loopcontrol load |
Load speed | Pressure resistance 0.05-20kN/S/rupture resistance 5-500N/S(selective) |
Error of testing force indicating value | ±2% |
Pressure plate diameter(mm) | φ155 |
Max piston stoke(mm) | 60 |
Mainframe dimension(mm) | 820×450×1300 |
Power | 1kW,AC220V±10% |
Weight(kg) | 450 |
