Help CenterYES-5000D 500ton Digital Compression Testing Equipment Price Concrete Pressure Tester Concrete Compression Testing Machine
Related Products
-
Manual Concrete Compression Test MachineUS$ 1,700 - 1,730MOQ: 1 Set -
YAW-300D Electronic Concrete Compressive Strength Testing MachineUS$ 3,500 - 3,500MOQ: 1 Set
-
YAW-300D 30Ton 300kN Computer Controlled Brick Cement Electric Motor Compression Testing EquipmentUS$ 1,800 - 2,000MOQ: 1 Set
-
YAW-100D 10Ton 100kN Computer Control Brick Cement Electric Motor Compression Testing MachineUS$ 1,800 - 2,000MOQ: 1 Set
-
YAW-200G 20Ton 200KN Computerized Mortar Cement Concrete Cubes Pressure Testing MachineUS$ 1,800 - 2,000MOQ: 1 Set
YES-1000/2000/3000D Digital Compression Testing Equipment Price Concrete Pressure Tester Concrete Compression Testing Machine
1. Application:
Applicable to make mechanical properties test of metal, nonmetal, jacks and other materials. Widely used by the construction, building materials, road and bridge, universities, industrial enterprises, quality supervision, metrology and other fields
2. Standard
1) GB / T2611-2007 "Tester General technical requirements"
2) JJG139-1999 "tension, pressure, and universal testing machine test procedures"
3) GB / T50081-2002 "ordinary concrete mechanical performance test method standards"
3. Features
1. The test machine with manual control, hydraulic loading, electronic measurement, digital display and automatic data processing, to be completed for compression test of metal and non-metallic materials. Accordance with the requirement of national standard GB / T50081-2002 "ordinary concrete mechanical performance test method standards"
2 Hydraulic system mainly controlled by the handle of the delivery oil valve and oil return valve, easy operation and ensure safe operation. The appearance of the test machine is neat appearance. The height of manipulating part and display part is appropriate, easy to operate and observe the experimenter.
3. The main unit adopting a four-column screw structure, the underneath cylinder , the motor drives the screw to adjust the test space; convenient sample handling and good stability.
4. Main technical parameter
Item | Technical parameter |
Max test forcer(kN) | 5000 |
Test Range(kN) | 2%-100%FS |
Test value accuracy | ≤±1% |
Max test space (mm) | 0-600mm |
Disatnce between columns (mm) | 500 mm |
Distance between upper and lower pressure plate (mm) | 400x400 |
Max piston stroke (mm) | 100 |
Loading rate | 0~40KN/s can adjust |
5. Main configuration
Item | Specification | Quantity | Remarks |
Main Unit | Inlcuding the lifting motor | 1 set | double electric ball screw |
Oil pressure sensor |
| 1 pc | In the control cabinet |
Oil source control cabinet | Inlcuding the test measuring software | 1 set | Including mini printer |
Upper and lower pressure plate | 400x400mm | 1 set | On the main unit |
Tool |
| 1 set |
|
Document |
| 1 set |
|
Test machine software |
| 1 set |
|
YES Series of CE Certificate
