Home > Products > thermic fluid heater > Industrial Oil/Gas Fired Thermal Fluid Heaters Hot Oil Boiler Price For Asphalt Production Line
Industrial Oil/Gas Fired Thermal Fluid Heaters Hot Oil Boiler Price For Asphalt Production Line
- 200 Set / Sets per Month
- Qingdao or Shanghai
- T/T L/C Other
- 15 days
- China Best Price Gas Oil Fired Thermal Fluid Hot Oil Boiler Heater price for Cardboard Industry
- 500kw-6600kw Diesel oil gas fired Thermal fluid oil heater, thermal oil boiler for Building materials industry
- Industrial Gas-fired Thermic Fluid heater, Oil-fired thermal Oil Boiler for Hot Press Machine
- 700kw-7000kw High Temperature Thermal fluid oil heater boiler for heat exchange equipment
- Industrial Boiler Oil Gas Fired Heat Transfer Fluid Heater, Thermal Oil Boiler For Road Bitumen Heating
- Industrial packaged type oil-fired thermal fluid heater/Thermal oil boiler for gypsum board drying
Product Details
Brand Name: | Jinzhen Boiler | Place of Origin: | China | Model Number: | YYW-1200 |
Certification: | CE | Type: | Natural Circulation | After-sales Service Provided: | Engineers available to service machinery overseas |
Weight: | 5000kgs | Dimension(L*W*H): | Φ1600*4800 | Condition: | New |
Style: | Horizontal | Fuel: | Oil-fired | Usage: | Industrial |
Output: | Other, hot oil | Structure: | Fire Tube | Pressure: | Low Pressure |
Product Description
Industrial Oil/Gas Fired Thermal Fluid Heaters Hot oil boiler price for asphalt production line
thermal capacity:350kw-1400KW
Working pressure:0.8-1.0 MPA
Outlet temperature:320 C
Available fuel:natural gas, coke oven gas, bio-gas,liquefied petroleum gas, diesel, heavy oil, light oil, crude oil
Available industries:Petroleum, chemical, chemical fiber, pharmaceutical, textile printing and dyeing, building materials, wood processing, vegetable oil processing and other industries
Oil gas fired thermic fluid heater is a kind of energy saving heating equipment, it can get a high temperature (around 350℃) under a low working pressure (0.8MPa). The working medium is hot oil, a circulating pump forced hot oil circulating in liquid phrase, and transfer heat to heat user equipment, then return back to the boiler for reheating. The fuel could be both oil and gas, based on the characteristics of fuel, the hot oil boiler could be equipped with different burners.
The organic heat carrier furnace(thermal oil heater boiler) is the once through special boiler, uses coal (bituminous coal, anthracite), light oil, heavy oil, liquefied petroleum gas, natural gas, artificial gas, waste wood, sanding powder, etc. as fuel, and the heat transfer oil is used as a heat carrier, and the circulating pump is used to force liquid phase circulation to transfer the heat energy to heat equipment, and then returns to the heating furnace to reheat the heat.
Diagram of thermal oil boiler
All thermal oil boilers are assembly structure which is easy for installation by just connecting system device by pipes. Intelligent system control of thermal oil fluid haters makes boiler operation easier and more simple. Controller with imitation screen display has auto igniting, burning, circulation pumps control, alarm, etc. functions. hot oil boiler|the
Technical Parameters:
Model No. | Thermal power(kcal/h) | Heating efficiency (%) | Max. working temp.(℃) | Medium circulation(M3/H) | Transport size (mm) | Weight (Kg) |
YY(Q)W-120Y(Q) | 10*104 | ≥92.26 | 340 | 12.5 | Φ1060*2045 | 1215 |
YY(Q)W-240Y(Q) | 20*104 | ≥92.26 | 340 | 18 | Φ1020*1980 | 1355 |
YY(Q)W-350Y(Q) | 30*104 | ≥92.26 | 340 | 30 | Φ1212*2310 | 1590 |
YY(Q)W-500Y(Q) | 40*104 | ≥92.26 | 340 | 30 | Φ1212*2730 | 1680 |
YY(Q)W-700Y(Q) | 60*104 | ≥92.26 | 340 | 60 | Φ1400*3410 | 2715 |
YY(Q)W-930Y(Q) | 80*104 | ≥92.26 | 340 | 80 | Φ1616*3400 | 3142 |
YY(Q)W-1200Y(Q) | 100*104 | ≥92.26 | 340 | 100 | Φ1616*4000 | 3660 |
YY(Q)W-1400Y(Q) | 120*104 | ≥92.26 | 340 | 100 | Φ1820*4905 | 5420 |
YY(Q)W-2000Y(Q) | 160*104 | ≥92.26 | 340 | 100 | Φ1840*4950 | 7850 |
YY(Q)W-2400Y(Q) | 200*104 | ≥92.26 | 340 | 160 | Φ2060*4700 | 8850 |
YY(Q)W-3000Y(Q) | 250*104 | ≥92.26 | 340 | 180 | Φ2060*5450 | 9210 |
YY(Q)W-3500Y(Q) | 300*104 | ≥92.26 | 340 | 200 | Φ2430*5965 | 9960 |
Performance characteristics:
1. Thermal oil boiler can obtain higher working temperature at lower operating pressure
2. Organic heat carrier furnace with complete automatic control and safety monitoring device
3. thermal oil heater boiler has good thermal stability and precise temperature adjustment
4. Natural gas thermal oil furnace with closed loop heating, high heat utilization efficiency
5. As a heating device, thermal oil boiler compared with a steam boiler, the energy saving effect is remarkable.
The thermal oil heaters in assembly structure is easy for installation by just connecting system devices. Intelligent control system makes heater operation control easy. Controller with screen display has auto igniting, burning, circulation pumps control, alarm and other control functions.
Application
The series of thermal oil heater is widely used in the following industries:
l Petrochemical Industries:polymerization, melted, condensation, distillation, removal H2.
l Oil industry:fat and acid distillation, grease decomposition, concentrated, esterification, vacuum deodorizer, high-temperature cooking, advanced salad oil.
l Synthetic fiber industry: polymerization, melt spinning, extending; drying.
l Textile printing and dyeing industry: heat setting, hot melt dyeing, melt bake calendering drying, high temperature stenter, oar yarn.
l Plastics and rubber industry:hot pressing, hot cast, vulcanization molding, calendering injection machine, plastic mixer, conveyor dryer, screw extruder.
l Paper Industry: dry, corrugated paper processing, egg tray, food cardboard drying, calendering machine, roller.
l Timber industry: multilayer plywood, fiberboard molding, plywood, wood drying, steaming equipment.
l Building materials industry: road bitumen heating, gypsum board drying, heating bitumen concrete, concrete elements curing, drying equipment.
l Air-conditioning industry:industrial plants, residential and hotel building heating.
l Detergent Industry: cooking boiler, autoclave, spray-washing tower, a conveyorized dryer, lipolysis device distillation column.
l The automotive industry:the tunnel-type drying room, degreasing baths, phosphate processing equipment.
l Electrical equipment industry: calendering machine, the platen machines, vacuum pan, dryer.
FAQ
What is the highest temperature that thermal oil heater could achieve?
thermal oil heater can reach as high as 330℃, and working under low pressure (<1.0MPa)
YY(Q)W series horizontal type oil gas fired thermal fluid heater.
What are the heat-resistance temperature of grate and furnace?
The heat resistance temperature of grate is related to the grate material, the highest temperature could be as high as 1100℃, and the lower temperature could be 700℃.
The highest heat resistance temperature of furnace could be about 1700℃~1800℃.
What is conduction oil/ hot oil / heat transfer fluid?
Conduction oil has a high boiling point, it usually used for the industries that need the temperature of 150~350℃, to instead of steam. The hot oil has the advantages of high transfer efficiency, fast heat transfer, and good thermal stability.
What about the maintenance?
I will offer you the timely maintenance way sheet after installation of the boiler mainly parts.
