1. INTRODUCTION
1.1 BASIC SAFETY INFORMATION
IMPORTANT!
Dangers, Warnings, and Cautions alert you to important
operating instructions or to potentially hazardous
situations. Pay special attention to these items.
THIS IS NOT A SMOKE ALARM! This CO Alarm is
designed to detect carbon monoxide from ANY source
of combustion. It is NOT designed to detect smoke, fire,
or any other gas.
This CO Alarm is approved for use in single-family
residences. It is NOT designed for marine use.
! CAUTION!
This CO Alarm will only indicate the presence of carbon
monoxide gas at the sensor. Carbon monoxide gas
may be present in other areas.
! WARNING!
The Silence Feature is for your convenience only and
will not correct a CO problem. Always check your home
for a potential problem after any alarm. Failure to do so
can result in injury or death.
This CO Alarm cannot operate without continuous
electricity. It does not operate during a power failure.
NEVER ignore your Carbon Monoxide Alarm if it alarms.
Failure to do so can result in injury or death.
Test the CO Alarm once a week. If the CO Alarm ever
fails to test correctly, have it replaced immediately! If
the CO Alarm is not working properly, it cannot alert you
to a problem.
This product is intended for use in ordinary indoor
locations of family living units. It is not designed to
measure CO levels in compliance with Occupational
Safety and Health Administration (OSHA) commercial
or industrial standards. Individuals with medical
conditions that may make them more sensitive to
carbon monoxide may consider using warning devices
which provide audible and visual signals for carbon
monoxide concentrations under 30 ppm. For additional
information on carbon monoxide and your medical
condition contact your physician.
1.2 HOW YOUR CO ALARM WORKS
GENERAL INFORMATION
CAUTION!
Leave your CO Alarm powered in year-round. CO problems
can occur any time during the year, and this Alarm can only
alert you if it is plugged in and receiving power.
This CO Alarm is intended for use in a standard AC220V
power supply. It is not intended for use in extension cords,
power strips, or outlets controlled by a switch or dimmer.
These may not provide continuous power to the unit.
When fully powered, it samples the air and takes a new
reading about every second. A microchip inside the unit
stores each reading, and remembers the levels of CO it has
been exposed to over time. The unit goes into alarm mode
when it has been exposed to a “critical” level of CO
(measured in parts per million or “ppm”) within a specified
time (measured in minutes).
This Carbon Monoxide Alarm features a permanently
installed sensor, three colored indicator lights, and an 85dB
alarm horn. It also has a Silence Feature to temporarily quiet
the alarm horn.
2. FEATURES
Detect carbon monoxide.
High quality durable electrochemistry sensor for CO
gas detection.
Easy to install.
Loud 80dB alarm and LED warning light.
Self diagnostic function by MCU intelligent software.
Excellent reliability & High stability.
Ideal for all house and kitchens.
3. TECHNICAL SPECIFICATIONS
Unit Dimensions: 122mm (H) x 76 mm (W) x 38mm (D)
Color: Ceiling White
Operating Temperature: -10°C to +50°C
Ambient Humidity: ≤95% RH
Alarm Horn: 80dB
Operating Voltage: AC220V/50HZ
Power Consumption:
Value of Detection Threshold (Lower Explosive Limit):
CO Gas: >150ppm (Alarm in 1 to 3 minutes)
Sensor lifetime: > 3 years
Alarm: Red LED with 80dB alarm
Warm Up Time: approximately 60 Seconds
Alarm Output: Voltage Output (DC12V pulse or steady)
(Only for Control Module)
