50 ton Galvanized Steel Plate Sectional Piece Type Bulk Cement Storage Silos , Fly Ash Storage Silos
Bulk Cement Tank Production Introduction:
1. Cement Silo also called cement bin storage silo, widely used in mobile cement mixing plant for road building, house building,bridge building, port transportation, etc., This cement silo is composed of steel sheets connected through bolts, it is very easy to assemble and disassemble. The experienced workers can finish the cement silo installation through the installation video or installation instruction.
2. This bolted cement silo is available for 50ton, 100ton, 200ton, 300ton, 500ton, 1000ton. The final size is designed according to local site requirements based on the local environment, so each cement silo solution is unique for customer.
Fly Ash Storage Silo Technical Parameters:
| Model | Tanker Diameter | Tanker Height | Capacity | Two sets silo transportation |
| 30 | 2.5m | 4.8m | 30T | |
| 50 | 3m | 7.6m | 50T | 1*40'HQ |
| 60 | 3m | 7.6m | 60T | 1*40'HQ |
| 80 | 3m | 11m | 80T | 1*40'HQ |
| 100 | 3m | 12.5m | 100T | 1*40'HQ |
| 200 | 4.5m | 19m | 200T | 1*40'HQ+1*20'GP |
| 300 | 5.5m | 21.3m | 300T | 2*40'HQ |
| 500 | 6m | 23.2m | 500T | In Bulk |
Sectional Piece Type Bulk Cement Tank has the following parts:
1. Dust removal system: an electric dust removal device is installed on the top of the cement chamber, which can effectively absorb suspended particles in the chamber and reduce pollution to the surrounding environment.
2. The lower cone of the cement chamber is equipped with a blow-air device, which USES the small electromagnetic reversing valve located in the air control chamber to control the release of compressed air to break the arch of cement and various powder materials, so as to avoid the blockage caused by powder accumulation.
3. Material level device: the material level device of cement silo can sense the storage height of material in the silo. 50 ton Sectional Piece Type Bulk Cement Tank , Fly Ash Storage Silos
Advantages of bolted cement silo:
1. excellent quality, nice looking .
All the parts of detachable cement silo are finished at factory with standard process, maintain stable and reliable quality. 50 ton Sectional Piece Type Bulk Cement Tank , Fly Ash Storage Silos
2. Detachable silos are easy for transportation, easy for assembling, easy for disassembling, save shipping space, reduced transportation cost.
3. Reliable sealing structure
Special sealing strip been compacted from 5 mm into 1 mm after bolted, strong elasticity to make all possible aperture fill compaction. It can stand high temperature at 200 - degree. It also can maintain long-time sealing effect in the wild. Finally fill the gap with glass glue to effectively prevent the summer rainy season moisture infiltration, and ensure it can improve the service life of sealting strip. 100 ton cement silo storage tank price for construction concrete mixing plant dry mix mortar plant
4. Simple and fast installation period
Detachable type powder silo realized the quick and easy installation. It can be used recycle.
| Precautions for use |
| 1. Check if the line is unblocked before use. |
| 2. Before and after the ash is injected into the tank, the bulk cement truck starts the vibration for 2-3 minutes. |
| 3. When the alarm on the cement tank alarms, stop the ashing to prevent damage to the dustproof processor. |
| 4. When the air outlet is not smooth, check whether the dust filter element is clogged. If it is blocked, it should be cleaned in time. 50 ton Sectional Piece Type Bulk Cement Tank , Fly Ash Storage Silos |
| 5. Before cleaning the filter element, first bundle it with 2-3 lines to prevent deformation of the filter element during rinsing. |
| 6. When cleaning, you must wait for the filter to dry before you can install it. |
| 7. After the filter element has been repeatedly cleaned, it should be replaced in time when it has reached the purpose of dust removal. 50 ton Sectional Piece Type Bulk Cement Tank , Fly Ash Storage Silos |
|
|
1. Henan Mind Machinery Equipment Co., Ltd. established in 2000, is located in China construction machinery city- Zhengzhou, the capital of Henan province.
2. Our company engaged in the dry powder mixing equipment R&D, production, sales and construction, providing most efficient turnkey solutions to our clients in green building energy-saving insulation and green wall (building) materials manufacturing equipment, production technology and construction program.
3. In addition, we have also obtained some authorized certifications, such like ISO 9001, CE, etc. OEM and ODM orders are acceptable for us. Welcome to contact us and talk your requirements.
1) FCL: in nude for standard exporting container
2) LCL: Poly wood case 50 ton Sectional Piece Type Bulk Cement Tank , Fly Ash Storage Silos
Wire cables are used for fastening the machine
Cork wood are placed in front or behind the machine to protect it.
Plastic film is covered on the machine as a rain-roof.
Crane is used during the whole loading.
Q: How long is your delivery time?
Generally within 30 days, it is according to order quantity, partial shipment is allowed for big order.
Q: How can I get the quotation of the project ?If you have drawing , we can offer you our quotation according to your drawing . If you have no drawing, our engineer will design the drawings for your confirmation first, then we offer you the quotation.
Q: Can you design? Is it for free?Yes. We have an excellent design team, to guarantee free, effective, accurate design for every customer. We always give very quick feedback for customer demands & modification. We ensure our design team will make the design that satisfy you.
Q: What about the installation?We will provide you the detailed installation drawings and manual which could help you to erect and install the building step by step. We also could send the engineer to your local to help you if need. If you have no work teams , we also can send our professional teams to install for you.
Q: What about Warranty of the products?The Mind Machinery grants our customers a twelve-month-period warranty from the date of delivery for machines exported from us. During the warranty period, in case any defect of material or workmanship occurred with spare parts in normal operation, we will at our discretion replace or repair the defective parts freely.
Q: The reason you choose our Machinery:1. Professional manufacturer of supplying mining crushing equipment, construction equipment, Ore beneficiation equipment and mining dryers. 50 ton Sectional Piece Type Bulk Cement Tank , Fly Ash Storage Silos
2. Experienced and professional R&D team and manufacturing team;
3. Professional sales team consisted of dedicated, dynamic and innovative people with international version.
4. Professional logistics service ensuring safety and timely delivery of products all over the world through ocean, airline, road 50 ton Sectional Piece Type Bulk Cement Tank , Fly Ash Storage Silos
