1700 Degree C Muffle Furnace
- SHANGHAI, SHENZHEN,NINGBO, QINGDAO
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 2020 days
You May Like
Product Details
| Brand Name | SRI | Place of Origin | China | |
| Model Number | MLS |
Product Description
Description
This muffle furnace is mainly used in laboratories for physical & chemical properties analysis, as well as sintering, dissolve, heat processing of metal and ceramics, electric elements, powder etc.
This muffle furnace adopts down opening design, easier for load and unload material; hearth made of new type ceramic fiber, better heat insulation, avoid scald. Can greatly reduce the Sintering temperature, max up to 500 degree C; up to 70-90% less power consumption; can greatly reduce the sintering time, up to 50%; greatly improve the tissue density, grain refinement, improve the material performance.
Technical specification
Furnace structure | Double layer steel casing with double cooling fans to ensure furnace surface temperature below 50oC. |
Chamber size | 200x200x200mm(or customized) |
Overall size | 560*660*820mm |
Max. temperature | 1700Degree C(normal work temperature 1600 degree C) |
Protection | Over-temperature and thermocouple-broken |
Temperature control | PID automatic control and auto-tune function. 30 programmable segments for precise control |
Heating rate | 0-20oC/min |
Temperature accuracy | +/- 1oC |
Heating element | SiC |
Working voltage | 220VAC, 50HZ |
Max. Power | 5kw |
Temperature measurement | B type thermocouple |
Net weight | 90kg |
Furnace structure | Vertical, bench, integration, seperated (optional) |
Door opening | Side, upper, bottom, slide |
Standard accessories | Crucible tongs, high temperature glove, thermocouple, pad |
