PV Moule testing machine /Solar panel static mechanical load tester with IEC61215-2:2016 testing standard
Testing standard
It's according to IEC61215-2:2016 testing standard
Purpose
This test is to determine the ability of the module to withstand wind , snow , static or ice loads
Testing machine's advantage
1. Dynamic & static integration,It’s can satisfy the Dynamic load testing, and also satisfy the Static load testing
2.The Static load mode:The positive load can realize +10000 Pa, the reverse load can
realize -6000 Pa
3.Dynamic load mode: Dynamic load:1000 Pa, 1000 times, the dynamic load
frequency:7s±3s
4.Cycle times:Free Setting
5.Pressure control accurate:5%
6.Real-time display the solar panel’s deformation, and drawing the force curve and
pressur curve
7. During testing, real-time monitor the current & voltage of solar panel
8. When the deformation value more than setting value, the machine will automatic
protection and stop
9.When the current more than seeting value, the machine will automatic protection and
stop
The Mainly Feature
The Testing machine’s raw material |
Aluminum profile structure (firm and Antirust) |
| Testing sample size | 2m×1m (customized) |
Pneumatic and force value feedback ways |
Low friction force cylinder, tensile pressure Sensor ( the accurate:0.1N) |
The cylinder |
8 pcs |
| The cylinder stroke | 125mm |
Surcker |
32 pcs |
| The sucker diameter | 120mm |
Control ways |
Computer control |
Software operate system feature
1,Computer operate and control software by HOTOTECH researched and
development,easy operate and test data stable
2,The software support Chinese and English , with the Switching function
3,Software real-time display pressure, deformation , testing time, cycle times and
current electricity continuity
4,Software real-time drawing pressure and deformation curve
5,Software real-time display each cylinder’s force value and drawing the force
value curve
6,Testing data real-time storage , query & print
7,The Testing data can export Word, Excel, PDF,JPG format
8,The software with the fault warning function
