PV module surface abrasions detection testing machine/solar panel anti-damage testing equipment with IEC61730-2:2016
Testing standard
It's conform IEC61215-2:2016 testing standard
Purpose
To determine whether any front and rear surfaces of the pv module made of polymeric materials are capable of withstanding routine handling during installation and maintenance without exposing personnel to the danger of electric shock
The Mainly parameter
Test stand frame raw materials |
Aluminum profile ( Firm and Antirust) |
| Testing sample size | 2m×1m (customized) |
|
Testing Fixture raw materials |
Use adopt carbon steel blade |
|
The steel blade thickness |
0.64mm±0.05mm |
|
The top angle of steel blade |
90±2° and with rounded with radius 0.115mm±0.025mm |
| The blade supply the force | 8.9N±0.5N |
| The test fixture speed | 150±30mm/s |
| Control ways and display ways | Touch screen |
| Electricity | 220V 50HZ |
Products images show
