Material: stainless steel 304, 304L, 304HC, 316, 316L, 321,430 or as per your request.
Application: The filter has been widely used in transformer oil, turbine oil, hydraulic oil, aviation kerosene, petroleum, chemical, power plant, coal carbon, mining, pharmaceutical, food, and engineering industries.
Customers can also avail customized sintered bronze filter cartridges, which are used mainly for liquid oxygen, compressed air and silencing with a filtration efficiency of 5 to 50 micron.
Advantage:
1. Strength: High mechanical strength and compressive strength.
2. Easy to clean: As a result of the surface of the filter material, having means for cleaning characteristics, especially suitable for backwashing.
3. Easy processing: suitable for cutting, bending, stamping, drawing, welding and other processes.
4. High temperature: 480 °Ccan withstand high temperatures.
5. Corrosion resistance: As a result of SUS316L, 304 materials, the corrosion resistance.
6. Filtration: Filtration range of 1μm-200μm, has a reliable filter performance.
7. Stability: Because there are two layers to do to protect the screen, plus solid melting diffusion sintering process which makes filters is not easy to deform.
Specifications:
|
Filtering Level |
Filtration Precision um |
Maximum Hole Diameter um |
Permeability Coefficient 10~12㎡ |
Permeability M3/h.㎡.kpa |
Thickness mm |
Compression Strength Mpa/cm2 |
Bubbling Pressure Kpa |
| S9 | 0.2 | 2.5 | 1 | 0.6~10 | 3.0 | ||
| S8 | 0.5 | 4 | 3 | 0.6~10 | 3.0 | ||
| S7 | 1.5 | 6 | 5 | 0.6~10 | 3.0 | ||
| S6 | 2.5 | 10 | 0.09 | 10 | 0.6~10 | 3.0 | 9.16 |
| S5 | 5 | 15 | 0.23 | 40 | 0.6~10 | 3.0 | 6.1 |
| 8 | 20 | 0.91 | 80 | 0.6~10 | 3.0 | 4.6 | |
| S4 | 10 | 30 | 1.81 | 160 | 0.6~10 | 3.0 | 2.6 |
| S3 | 28 | 60 | 3.82 | 350 | 0.6~10 | 3.0 | 1.8 |
| 35 | 80 | 7.29 | 500 | 0.6~10 | 3.0 | 1.4 | |
| S2 | 40 | 100 | 9.43 | 700 | 0.6~10 | 3.0 | 1.1 |
| S1 | 65 | 160 | 15.1 | 1000 | 0.6~10 | 3.0 | 0.66 |
The standard five-layer mesh is composed of protective layer, precision control layer, dispersion layer, two strengthening layers.
1. protection layer
On the control layer for protection and protection in the process of maintaining stability in micro-pore shape and size.
2. control layer
Precise wire mesh as a key work of the sintered filter materials, sintered wire mesh filtration accuracy by its control.
3. dispersion layer
Filter media by sintered mesh control, guide to the filter media stream and keep control of micro-hole shape and dimensional stability.
4. strengthening layer
Wire diameter coarse pores larger wire for support, to improve overall strength and stiffness of the sintered wire mesh.
Application:
Prodoction process
