Help CenterXY-180 Large Diameter 100-meter Geological Exploration Core Drilling Machine Water Well Drilling Rig
Related Products
-
XY-200 Water Well Drilling Rig Hydraulic Core Drilling Machine Building Foundation Survey EquipmentUS$ 6000 - 7500MOQ: 1 Set -
Metal Mine Full Hydraulic Steel Obtained Core Prospecting RigUS$ 4000 - 6000MOQ: 1 Set
-
KY-250 Water and Gas Exploration Drilling Rig/metal Exploration Drilling RigUS$ 4000 - 5500MOQ: 1 Set
-
KY-300 Tunnel Core Drilling Rig Underground Mine Water Well Drilling RigUS$ 4000 - 6000MOQ: 1 Set
-
KY-6075 Water and Gas Exploration Drilling Rig/metal Exploration Drilling RigUS$ 4000 - 6000MOQ: 1 Set
1.The main charateristic of XY-180 water well drilling rig
a.The XY-180 drill is designed on the basis of the XY-150 drill. It is a low speed and high torque portable drilling machine with oil pressure.
b.This drill is suitable for engineering geological survey of railway, hydropower, traffic, bridge, dam foundation and other buildings.
c.Geological core drilling and physical investigation.
d.Drilling holes for small holes and blasting holes.
e.A small water well drilled.
2.The technical parameter of XY-180 drilling rig
Drilling depth（m） |
180,150,120,90,70,30 |
Borehole diameter（mm） |
75,91,110,130,150,300 |
Maximum opening diameter（mm） |
375 |
drill pipe diameter（mm） |
42、50 |
Spindle Speed (r/min) |
71,142,310,620 |
SpindleStroke（mm） |
450 |
Upgrading Ability (KN) |
15 |
Diameter of steel wire（mm） |
12 |
Type |
gear pump |
Model |
YBC-12/80 |
Rated pressure (MPa) |
8 |
Rated speed (r/m) |
1500 |
Displacement（ml/r） |
8 |
Power supply |
ZS1115 diesel engine and 15kw motor |
