Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > CJD-300 Crawler Pneumatic Water Well Drilling Rig Flexible and Efficient
CJD-300 Crawler Pneumatic Water Well Drilling Rig Flexible and Efficient
US$ 5000 - 7000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia Master
Place of Origin:
China
Model Number:
CJD-300
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
7 days
Related Products
-
JDL-300 Mud/Air Drilling RigUS$ 26400 - 30000MOQ: 1 Set -
JDL-350 Mechanical Top Drive Water and Gas Drilling RigUS$ 26400 - 30000MOQ: 1 Set
-
JDL-400 Mud/Air Drilling RigUS$ 26400 - 30000MOQ: 1 Set
-
KQZ-200D 100 Meters Pneumatic Rock Drilling Rig Small Pneumatic Water Well Drilling MachineUS$ 4000 - 6000MOQ: 1 Set
-
KQZ-180D Small Pneumatic Drilling Machine Combined Gas and Electric Drilling MachineUS$ 4000 - 6000MOQ: 1 Set
Brand Name
Huaxia Master
Place of Origin
China
Model Number
CJD-300
Type
Rotary Drilling Rig
Certification
iso 9001
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
one year
Weight
8 T
Dimension(L*W*H)
4350*1850*2750 mm
Power Type
Diesel
Voltage
380 V
Usage
Water Well
Condition
New
Power(W)
85 KW
The applications of CJD-300 crawler pneumatic water well drilling rig
civil engineering drilling
geothermal drilling,
drilling with large diameter and deep drilling footage
It’s fast, flexible and efficient
The specifications of CJD-300 crawler pneumatic water well drilling rig
Model |
CJD-300 |
|
Gross weight |
t |
8.8 |
Dimension |
mm |
4350*1850*2750 |
Aperture |
mm |
140-325 |
Drilling depth |
m |
300 |
Feed stroke |
mm |
6000 |
Travel speed |
km/h |
2 |
Grade ability |
max. |
30° |
Rising height from ground |
mm |
230 |
Wind pressure |
mpa |
1.7-3.3 |
Air consumption |
m³/min |
23 |
Engine power |
kw |
85 |
Rotary speed |
rpm |
55-115 |
Rotation torque |
n.m |
7200-8500 |
