.A brief introduction of QTZ-3D portable electric soil drill
QTZ-3D portable electric earth drill is an electric version of the QTZ-3 type gasoline engine earth drill rig of Shandong Master Machinery Group Co.,Ltd.
The improvement of QTZ-3D electric earth drilling rig is mainly engine system than that of QTZ-3 gasoline drilling rig. The QTZ-3D electric earth drilling rig selects pure copper winding two phase electric motor as a power source. The advantage of using the gasoline engine as the power source is its stability, and it can continuously improve the working efficiency with a certain kind of power operation equipment. It greatly improves the feed speed. In addition, QTZ-3D electric earth drilling rig is easy to operate, safe and stable, and can greatly reduce the labor force of soil sampling personnel.
2.Application field of QTZ-3D portable electric soil drilling rig
Geotechnical investigation; environmental soil survey; agricultural soil survey;
Groundwater survey; coastal geological survey; wetland environmental investigation;
Tailing pond investigation, archaeological investigation, physical chemistry exploration secondary halo sampling; The description of soil structure.
3.Technical parameters of QTZ-3D portable electric earth drilling rig
QTZ-3D portable electric earth drilling rig | |
Voltage |
220v |
Power |
3.6kw |
Fire mode |
Switch mode |
energy consumption |
Low power consumption |
Impact times |
2600min/m |
Impact energy |
60j-79j |
Core depth |
15m-20m |
Host weight |
22kg |
4.QTZ-3D portable electric driller configuration list
Name |
Model |
Unit |
Quantity |
Electric earth drilling rig |
QTZ-3D |
Platform |
1 |
Shock reception |
32*150 |
Pcs |
1 |
Cones |
32*80 |
Pcs |
19 |
Drill pipe |
32*700 |
Root |
19 |
Taper wire |
32*100 |
Pcs |
19 |
head |
32*50 |
Pcs |
1 |
Hoop |
50*150 |
Pcs |
1 |
Open tube |
50*600 |
Root |
1 |
Double-edged pipe boots |
50*100 |
Pcs |
2 |
Head |
32*70 |
Pcs |
1 |
Hoop |
70*150 |
Pcs |
1 |
Open tube |
70*600 |
Root |
1 |
Inner edge pipe boots |
70*100 |
Pcs |
1 |
Outer edge pipe boots |
70*100 |
Pcs |
1 |
Portable sounding hammer |
10kg |
Pcs |
1 |
Sounding the head |
32 |
Pcs |
1 |
Double sided hand |
32 |
Pcs |
1 |
Touch probe |
32 |
Pcs |
1 |
Puller |
Three force arm |
Set |
1 |
Pipe forceps |
80mm |
Hold |
1 |
Hold-all |
Pcs |
1 |
