Parameters that
Intake air pressure range:2 bar - 7 bar (0.2 Mpa to 0.7 Mpa)
The power supply voltage:Ac 220 v
Power:0.02 kw
Pressure range of output:0.6 tons to 8 tons infinitely adjustable
Total trip:100 mm (including power trip)
Power stroke:6 mm
High throat:385 mm
Deep throat:500 mm
The fastest frequency of use:1 time / 1 second
Trip gas consumption:1.3 liters / 1 times
Overall dimensions of equipment:(long) 1030 mm * 650 mm (wide) * 2060 mm (high)
The weight of equipment:500 kg
Model description: QY - gas-liquid booster drive (economy, high efficiency, energy saving, environmental protection)
8 - output pressure (tons)
500 - deep throat (MM)
C - C type cast steel frame (frame 45 # integral cast steel forming, overall processing)
Z - intelligent pressure controller (control) pressure accurately
The characteristics of the gas and liquid pressurization technology:
1, gas-liquid pressurization technology is a collection of pneumatic and hydraulic combines the advantages of both;
2, 6 bar of ordinary compressed air, driven to produce 2 tons - 100 tons of blunt pressure, without hydraulic system;
3, advanced technical guarantee in place of "soft" no impact vibration, greatly reduces the noise, and greatly improve the machining quality of workpiece stamping die life;
4, unique "adaptive" technology ensure impact pressure to adapt and adjust automatically according to the resistance change, realize the stamping process of * * *;
5, pneumatic control system, simple and reliable, convenient operation and maintenance;
6 work pressure, can according to the processing needs stepless adjustable, full use of pressure control to ensure the consistency of product processing, guarantee in the course of processing is not affected by the thickness of the product error;
7, the advanced seal technology, to ensure long-term free maintenance work;
8 and very low energy consumption.
9, high action frequency.
Scope of application:
Widely used in the chassis cabinets, electrical appliances, LCD stent, self-help housing payment terminals, logistics equipment, communication products and computer shell strong connection between the components.
High output of new torque resistance, resistance to the top of the applicable Yu Gangtong, copper, aluminum and aluminum alloy coin.
