Introduction
Spring cone crusher machine is suitable for crushing all kinds of ores and rocks with medium or higher hardness.Its spring safety system is overload protection device, can make the metal foreign body through the crushing cavity and do not harm the machine, with dry oil or water sealing form, so that stone powder and lubricating oil isolation, ensure reliable work.The type of crushing chamber is determined by the use of ore.Standard type is suitable for medium crushing, medium size is suitable for fine crushing, short head type is suitable for ultra-fine crushing.It has the characteristics of reliable structure, high production efficiency, convenient adjustment and economical use.
Characteristic
Gaskets
The nipping clearance of bevel gears and the height of suspension point can be adjusted by increasing or decreasing the gasket, which can change the position of spindle and cone bushing, thus causing the gap change.
Unique cavity shape
The material is sandwiched between two cones and subjected to extrusion, bending and shearing, which makes it easier to crush and lower power consumption.
Overload protection
Overload protection, extend the service life of the equipment.
Bearing
Higher motion speed, more uniform product material, cube shape, high productivity.
Technical Parameter
Model |
Specification |
Maximum Granularity
mm |
Adjustable Scope of Outlet mm |
Capacity
t/h |
Main Motor Power kw |
Weight t |
|
|
Crushing Wall Diameter mm |
Feeding Inlet Width mm |
||||||
|
PYB- 0607 PYB- 0609 PYB- 0611 |
600
|
70 95 110 |
60 80 90 |
6~38 10~38 13~38 |
15~50 18~65 22~70 |
≦22 |
4.5 |
|
PYB-0910 PYB-0917 PYB-0918 |
900 |
100 175 180 |
85 145 150 |
10~22 13~38 25~38 |
45~90 55~160 110~160 |
≦75 |
10.0 |
|
PYB-1213 PYB-1215 PYB-1219 PYB-1225 |
1200 |
133 155 190 250 |
110 130 160 210 |
10~30 13~38 19~50 23~50 |
60~165 100~195 140~300 190~310 |
≦110 |
17.0 |
|
PYB-1313 PYB-1321 PYB-1324 PYB-1326 |
1300 |
135 210 240 260 |
115 175 205 220 |
13~ 30 16~38 19~50 25~50 |
105~180 130~250 170~345 230~335 |
≦150 |
22.5 |
|
PYB-1721 PYB-1724 PYB-1727 PYB-1737 |
1750 |
210 240 270 370 |
175 205 230 310 |
16~38 22~50 25~64 38~64 |
180~320 255~410 290~630 430~680 |
≦220 |
43.5 |
|
PYB-2228 PYB-2233 PYB-2237 PYB-2246 |
2200 |
280 330 370 460 |
235 280 310 390 |
19~38 25~50 32~64 38~64 |
380~725 600~990 780~1270 870~1360 |
≦280 |
67.5 |
|
PYBZ-2228 PYBZ-2223 PYBZ-2237 PYBZ-2246 |
2200 |
280 330 370 460 |
235 280 310 390 |
19~38 25~50 32~64 38~64 |
540~1020 855~1410 1110~1800 1240~1920 |
≦375 |
87.5 |
