Introduction
The PE series of jaw crusher is used for coarse crushing, PEX series for medium and fine crushing, all kinds of machines have beautiful shape and excellent quality.It is used in the field of mining to crush hard or medium hard ores coarsely or moderately, crushing all kinds of materials with compressive strength not exceeding 320 Mpa.
Advantage
1. Overall cast steel technology, reliable and beautiful
The core load-bearing parts of jaw -- moving jaw body and bearing seat, we adopt high-quality high manganese steel castings, which can not only ensure the seamless joint of crusher, but also greatly increase the durability of vulnerable parts.
2. Optimize the cavity structure, high efficiency and energy saving
The crushing cavity is deep and there is no dead zone, the feeding and crushing ratio is large, the motion parameters of the moving jaw are optimized, and the crushing efficiency of the equipment is higher under the same energy consumption, the energy saving of single machine is 15%-30%, and the energy saving of the system is more than twice.
3. Protective device, safe against overload
Jaw crusher bracket is not only a force transmission component, but also a protective device.When the crusher falls into the material that cannot be broken or cannot be borne, the bracket will automatically break, and the crusher will stop working, avoiding the damage of the machine and ensuring the safety of production.
4. Flexible adjustment of discharge port, multi-purpose for one machine
Gasket type discharge opening adjustment device, so that discharge opening adjustment range, enhance the flexibility of the use of equipment, one machine multi-purpose, meet customer requirements for a variety of processing.
5. Tooth shape plate design, higher output
The effective length of the jaw plate is increased by adopting the tooth-shaped guard plate, which makes the discharging particle size uniform and the output higher.
6. Lubrication system is safe and easy to maintain
The equipment adopts grease concentrated lubrication, safe and reliable, easy to replace parts, and easy to maintain.The overall structure of the machine is simple and more stable.
Technical Parameter
Model |
|
Maximum Feeding Granularity (mm) |
Adjustable Range of Discharging Outlet (mm) |
Capacity (t/h) |
Eccentric Shaft Rotary Speed (r/min) |
Motor Power (kw) |
Total Weight (t) |
Outer Dimension (L×W×H) (mm) |
PE-150×250 |
150×250 |
125 |
10-40 |
1-3 |
250 |
5.5 |
0.8 |
720×660×850 |
PE-200×300 |
200×300 |
180 |
15-50 |
2-6 |
260 |
7.5 |
1.2 |
910×750×990 |
PE-200×350 |
200×350 |
180 |
18-70 |
3-10 |
260 |
11 |
1.5 |
1000×870×990 |
PE-250×400 |
250×400 |
210 |
20-60 |
5-20 |
300 |
15 |
2.8 |
1300×1090×1270 |
PE-400×600 |
400×600 |
340 |
40-100 |
16-60 |
275 |
30 |
7 |
1730×1730×1630 |
PE-500×750 |
500×750 |
425 |
50-100 |
40-110 |
275 |
55 |
12 |
1980×2080×1870 |
PE-600×750 |
600×750 |
500 |
150-200 |
80-240 |
275 |
55 |
15.8 |
2070×2000×1920 |
PE-600×900 |
600×900 |
500 |
65-160 |
50-180 |
250 |
55 |
17 |
2190×2206×2300 |
PE-750×1060 |
750×1060 |
630 |
80-140 |
110-320 |
250 |
110 |
29 |
2660×2430×2800 |
