Help CenterInternal Antenna MIFARE DESFire Reader Module, Embedded IC Card RFID Module UART TTL Interface
Related Products
-
Inbuilt TTL NFC Reader Module, Internal Antenna RFID Reader Writer Module, ISO14443ANegotiableMOQ: 1 Piece -
Inbuilt TTL MIFARE DESFire EV1/EV2/EV3 Reader Writer, ISO14443A/B, ISO15693NegotiableMOQ: 1 Piece
-
Inbuilt Antenna MIFARE DESFire EV2/EV3 RFID Module, 13.56MHz Reader ModuleNegotiableMOQ: 1 Piece
-
RS232 Inbuilt Antenna MIFARE Reader Module, NFC RFID Reader Writer, ISO14443ANegotiableMOQ: 1 Piece
-
USB Inbuilt Antenna MIFARE DESFire RFID Module, DESFire EV3 Reader Module 13.56MHzNegotiableMOQ: 1 Piece
Key Features:
DC3.3V ~5V power supply, UART-TTL interface;
Compliant with ISO14443A/B, ISO15693 standard;
Available with ISO7816 T=1 PSAM card;
Support MIFARE®DESFire EV1/EV2/EV3, MIFARE®Plus, MIFARE® Classic 1K /4K, MIFARE Ultralight® / Ultralight® C,MIFARE® PRO, ISO14443A-4 contactless CPU card, I CODE SLI, TI 2048, etc ;
Available to operate DESFire PICC level, Application ID create/delete/format, etc;
Support to create Standard DataFile&BackupFile, and ValueFile, RecordFile, etc;
Inbuilt antenna on board, reading range up to 4cm ~ 10cm
Technical Parameters:
Electrical Specification |
|
Power supply |
DC 3.3V ~ 5V |
Power consumption |
Max current： |
Operation frequency |
13.56MHz |
Baudrate |
9600~115200 bit/s ( default 9600bps) |
Interface |
UART TTL |
Antenna |
Inbuilt on board |
Reading range |
Up to 4 cm ~ 10 cm( depends on antenna and cards) |
Mechanical Specifications |
|
Dimension |
34.5mmx58mmx3mm (LxWxH) |
|
8g |
|
FR4, Blue |
Model |
CHK343MT |
Environmental Conditions |
|
Operation temperature |
-20°C～ +80°C |
Storage temperature |
-40°C～ +85°C |
Humidity |
Relative humidity 5%～95% |
Supported Standard/ Tags |
|
ISO14443 A |
Read/write: MIFARE® Classic 1K /4K, MIFARE Ultralight®, MIFARE Ultralight® C, MIFARE® DESFire®EV1/EV2/EV3, MIFARE® Smart MX, MIFARE® Plus S / X, MIFARE® Pro X, NTAG 21x, Sony Felica, etc
Read UID only: Read UID only of all other ISO14443A RFID tags |
ISO14443 B |
SRI4K, SRIX4K, AT88RF020, 66CL160S, SR176 |
ISO15693 |
EM4135, EM4043, EM4x33, EM4x35, I-Code SLI / SLIX, M24LR16/64, TI Tag-it HF-I, SRF55Vxx (my-d vicinity) |
SDK information |
|
Demo software |
WINDOWS, C# language |
Files |
Comprotocol document API document User Manual Demo.exe |
Note: Other functions and details to be continued and upgrade
