8m 10m 12m Electro Screw Mechanical Telescopic Mast

8m 10m 12m Electro Screw Mechanical Telescopic Mast thumbnail-1
8m 10m 12m Electro Screw Mechanical Telescopic Mast thumbnail-2
8m 10m 12m Electro Screw Mechanical Telescopic Mast photo-1
8m 10m 12m Electro Screw Mechanical Telescopic Mast photo-2
US$ 1,010 - 1,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
electro mechanical mast
Place of Origin:
Tianjin, China
Model Number:
TAL-M-008
Contact Supplier Request Quote Chat Now
Dingzhou City Great Wall Daily Chemical Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing airport China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name electro mechanical mast
Place of Origin Tianjin, China
Model Number TAL-M-008
Product Description

                                    8m 10m 12m electro screw mechanical telescopic mast


Specifications
Closed length
2.2m (Bottom base included)
Extended length
8.0m (Bottom base included)
Wind load
working rate:25m/s Max rate:35m/s
Temperature
working temp:-40--+50C Storage Temp:-55--+70C
Top Loading
30kg
Section numbers
6
Bottom plate
Length:550mm width:320mm
Material
Main Pole: aluminum alloy
Bottom base and accessories(except the stakes): iron steel
Pulling cord: galvanized steel wire(OD:2mm)
Color
Army green
Technology
painting
Wall thickness
2.0-2.0-2.0-2.0-2.5-5.0mm
Diameter range
40-105mm

Application


The electro screw mechanical telescopic mast is suitable for car,ship or land.It can help light transmission and camera and other equipment rise to a predetermined height and drop to a predetermined height after its work. Our company's products are also widely used in golf, soccer stadium lighting at night.


Detailed Images

Main pole in 6 sections


Section No.
OD(mm)
Thickness(mm)
1
40
2.0
2
50
2.0
3
60
2.0
4
70
2.0
5
80
2.0
6
90
2.0
6
105
2.5
Accessories of  electro screw mechanical telescopic mast
Main pole
1 set
Pulling cord box with handle bars
3 units
Ground anchor
3 pieces
Handle lifting bar
1 piece
Electrical equipment control box
1 unit
Remote-controller with wire
2 pieces
Limitator(1.4m length)
1 unit
Tripod
1 unit

Ground anchor


only reference for Remote-controller with wire

Control box


Control box


Handle bar for Pulling cord box

Handle bar for lifting the mast


Packing & Delivery

PACKING:

     Each unit of electro screw mechanical telescopic mast (main pole and all accessories) to be wrapped with Poly tapes and then into a wooden case.

    The Control box to be packed into a separate wooden case.


WARRATY PERIOD

      Except the damages due to misuse,unauthorized modification and man-made sabotage, the damaged parts will enjoyed free after-sales maintenance within one year's time from the date of delivery on the condition that the buyer himself will bear the shipping cost back and forth and the said damage should be confirmed by the seller through photos and description.

Installation Instructions:

1)The electro screw mechanical telescopic mast can be installed on the ground, or on the vehicle. No matter where to install, its installation shall keep vertical with the ground.Tilted telescopic antenna mast will affect the rise and fall of itself, and if the lifting rod tilts seriously or maintain a long time, damage and danger could not be avoided.
2)The electro screw mechanical telescopic mast needs to be installed on a fixed object, without any shaking, such as walls, car body, or pile. At least two fixed points will be installed, and one point must be installed on the body of the telescopic antenna mast. And the distance between two points should be longer than 2/3 of the height of telescopic antenna mast. Its connection must be solid and reliable.

Our Company
Related Products
Extended length(m)
Retracted length(m)
Section number
Diameter range(mm)
Top loading
2
1.0
3
40-60
30
2
0.75
6
40-90
20
2
1.2
2
105-130
100
3
1.75
3
90-130
250
4
1.8
3
90-130
250
4
1.55
4
40-80
10
4
1.2
6
60-130
50
5
1.4
6
60-160
150
5
1.6
5
60-150
600
6
1.7
6
40-90
10
6
1.7
6
50-105
50
8
2.2
6
40-105
30
10
2.45
7
40-105
30
12
2.45
7
40-105
200
12
2.3
7
70-160
35
12
2.7
7
40-130
100
12
2.4
7
50-130
20
15
2.8
7
50-130
20
15
2.2
7
60-155
30
15
2.7
7
70-230
300
20
3.7
7
60-230
200
25
3.4
10
60-230
80
25
3.4
10
60-210
60
28.5
3.7
10
30-130
15
35
3.9
11
30-180
10

Other products:

 Actually, apart from this,we also have many masts available: hand lifting, motorized lifting and pneumatic lifting with extended length from 2 meters to 45 meters, the largest play loads up to 300 kgs. We could make appropriate adjustments with different sizes and colors specially for you.
