Aluminum profile window and door double head cutting saw aluminum window machine
- 50 Set / Sets per Month
- Qingdao
- T/T Credit Card
- China small type clamping multi pieces profiles LXD-200 Aluminum Profile Small End Milling Machine
- Small Surface End Milling Machine
- China small aluminum window door end milling machine price
- LXDA-200 small size aluminum window door end milling machine
- aluminium Saw machine quotes
- PVC Window Door Production Line Saw Cutter Double Head Miter Saw
Product Details
Brand Name: | Mingmei | Model Number: | SKZXR-600x5300 |
Packaging Details
plastic film or Strongel Wooden Case for Extra-wide Aluminium Profile Processing CNC Arbitrary Angle Double Head Cutting Saw
Product Description
Quality is our Culture!
Extra-wide Aluminium Profile Processing CNC Arbitrary Angle Double Head Cutting Saw
1.Main Features for Industrial Aluminum CNC Heavy Duty Arbitrary Angle Double Head Cutting Saw |
1.1 It is new designed to meet the development of modern aluminum curtain wall,aluminum template processing industry and radiator industry. 1.2 It is mainly used for processing of extra-wide aluminum profile, also can be used to process aluminum profile vertical end-face material -discharging. 1.3 Adopt servo motor to drive reducer, implement saw blade rotating positioning at any angle between 45°and 90°. 1.4 Two cutting heads can swing positioning at any angle between 45°and 90°. 1.5 Two cutting heads not only can work separately, moveable head feeding material continuously,fixed cutting head cuttingcircularly; but also can work simultaneously, can cut needed length and profile two ends angle at one time. 1.6 Hard alloy teeth cutting blade, high cutting speed,high produce efficiency,high process accuracy. |
2.Specifications for Industrial Aluminum CNC Heavy Duty Arbitrary Angle Double Head Cutting Saw |
Model | SKZXR-600x5300 | |
2.1 | Power Supply | three phase four wire 380V/50Hz (Can be produce according to clients .) |
2.2 | The motor of the saw head | power 3 X 2 kw |
2.3 | Motor Rotary Speed | 2800r/min |
2.4 | The saw wings servo motor | power 0.9 x 2 kw |
2.5 | The head horizontal moving servo motor | power 1.5 kw |
2.6 | The head angle motor | power 0.18 x 2 kw |
2.7 | The Air Pressure | 0.5MPa~0.8MPa |
2.8 | Cutting Length | max 5300mm |
2.9 | Cutting Width X Height | max 500X180 mm (90°) |
2.10 | Cutting Height Max | 210 mm (90°) |
2.11 | Cutting Angle | Saw Blade 45°~ 90° Machine head 45°~ 90° |
2.12 | The feeding speed | Speed Governing Continuously 0~ 3m/min |
2.13 | Saw Blade Specification | φ600mm×4.4mm×φ30mm Z=120 |
2.14 | Overall Dimension | 7500mm×2450mm×1700mm |
2.15 | Weight about | 5100kg |
3.Detailed Images for your reference |
------Machine on 2016 Guangzhou Exhibition
-------Cutting Any angle (Saw blade turn and worktable turn)from 45 to 90 degree with digital display |
4.Applicable materials of Industrial Aluminum CNC Heavy Duty Arbitrary Angle Double Head Cutting Saw |
5.Certifications of Mingmei CNC Machinery |
We Will Provide You The Professional Service Do Not Hesitate To Contact With Me. |
What we can do for customers? |
-Trade Asssurance -Pre-Sales Service * Inquiry and consulting support. * Design drawing of the factory workshop -After-Sales Service * One year warranty time, we can repair and replace parts for free in one year. * Engineers available to service machinery overseas. *We provide the consumable parts at agent price when you need replacement With us your money in safe,your business in safe! . |
How about the Packing&Delivery? |
Packaging:These machines will be packed with Plastic Film and standard export wooden case, to make sure customer will receive the machines they ordered Intact. Shipping:Shipping by 20GP,40GP,40HQ Container... According to Customers’ location and the vehicle size , we will provide professional packaging can save sea freight for cutomers. |
Shandong Mingmei CNC Machinery Co., Ltd |
MMCNC was found in 1995,which is a modern private enterprise specialized in technology development,machinery manufacture and product sales.Company cover an area of 70000 square meters and 200 staffs. MMCNC machine include Processing machine for making aluminum PVC window and door as well as curtain wall, such as--- Double head Cutting Saw;Corner Crimping Machine;End miller;Copy router;PVC Welding Machine;Corner Cleaning Machine; we also produce CNC Router etc.which these machine have got CE,ECM,EEC authorization .and it has won good market reputation.
Thank you for your interest in our products, we welcome new and old customers contact us for future business relationships and achieving mutual success! |
Company&Plant |
Exhibition-Shanghai,Beijing,Guangzhou... |
Clients Visit |
What's FAQ? |
1. Q: Are you a factory or trading company? A: We are china one of famous factory for Aluminum /PVC Window Door Making Machine, Insulating CNC Router, CNC milling and Drilling Machine Center for Aluminum and Curtain Wall. Welcome to visit our web: 2. Q: which is the nearest international airport and domestic airport ? Can I visit there? A: Yes , you can. Jinan airport is the nearest domestic air port in Shandong province. 3. Q: How does your factory do regarding quality control? A:We have strict control in testing of raw material, production process and final process.Only qualified products can be sent out.And we have passed ISO,CE certificate. 4.Q:What you can do if my machines have problems? A: a.We can send you free components to you if your machines are in guarantee time. b.We can send our engineers to repair your machines 5. Q: If OEM available? A: Yes, as we usually do. 6.When can we arrange shippment? A:We usually arrange shippment in 15 days after getting deopsit, but customized machines should be more than 25 days. 7.What's your payment methods? A: L/C, 30% deposit by T/T,70% spare payment L/C. |
MINGMEI CNC: Supplying the most durable CNC machine is our lifelong promise!
Jessica Jia (Sales Manager)
Tel: 008613225317062
Skype: falconhatred
Email: info@sdmmcnc.com
Company Profile
Based on the principle of "people-oriented, honesty first", we have set up more than ten offices all over the country, equipped with sales and service engineers with rich experience in industry services, providing reliable technical services and product sales consultations at any time. Our aluminum door and window equipment, plastic steel door and window equipment, insulating glass equipment, glass deep processing equipment have been exported to the United States, Russia, Canada, Mexico, United Arab Emirates, Indonesia, Mauritius, Yemen, Vietnam, North Korea, Saudi Arabia and other nearly 30 countries and regions. , deeply praised by foreign users. As a professional manufacturer of door and window equipment, plastic steel door and window equipment, aluminum door and window equipment, insulating glass equipment and glass deep processing equipment, we rely on our own scientific research strength to continuously update and improve product quality and service. We are looking for friends in the door and window industry with more competitive prices and more thoughtful after-sales service.
