DECALUMA Single Head Arbitrary Angle Cutting Saw
Specification:
lUsed for curtain wall and window of aluminum accurate cutting ,also for UPVC profile.
lSingle head any angle cutting saw with the carbide saw blade, which make sure the high speed and accurate cutting.
lThis machine can be installed the size positioning frame, also can added the digital display device according to your requirement, thus can make the locating size more accurate.
lThe workbench rotating between the left (-15 °)~90°~(+15°). after the plate retrocession, the workbench can be 0°positioning, then raise and fix the saw blade thus this machine can be used as Routing saw.
Technical Parameter::
Power supply |
380V 50Hz,three phase |
motor power |
1.5Kw |
air pressure |
0.5~0.8MPa |
air consumption |
0.03m³/min |
motor rotation speed |
2800r/min |
Blade feeding speed |
stepless timing 0~3m/min |
cutting angle |
(-15°) ~90°~(+15°) |
Cutting profile surface plane |
≤0.10mm |
Cutting angle tolerance |
Ra12.5 μm |
Cutting width |
165mm,90°MAX |
Cutting height |
123mm,90°,MAX |
saw blade specification |
φ400mm×3.5mm×φ30mm Z=80 |
Overall dimension |
5000*900*1300mm |
Weight |
600Kg |
1.Product capacity: 20Sets/month
1.MOQ: 1 Set
2. Deliver time: within one week
3.Trade term: FOB qingdao, or CIF, C&F
4.Payment term: 30% inadvance, then L/C or TT
