Digital Display Double Head Cutting Saw LJZ2C-500*4200A
Specification:
- Designed for Aluminum, PVC and Curtain-wall profile accurate Cutting
- Digital display system equipped can be easy readout the accurate cutting length and quantity automatically, ensures a high accurate re-load position and convenient man operation work.
- Linear bearing system in moving and feeding device ensures the accurate the machine running and cutting, and stable performance.
- Two heads can work together or lonely,when together work ,one time can cut off the required length and angle.
- Hydraulic cylinder ensured the stable speed adjusting and saw blade working.
- Automatic angle cutting can be changed in 45° and 90°.
- Carbide saw blade for a high quality cutting and life.
- Safety system of shield can ensure the safe operation of man working.
Technical Parameter:
Power supply | Made to order |
Motor power | 2*2.2KW |
Motor rotary speed | 3400r/min |
Operation air pressure | 0.5~0.8Mpa |
Saw blades length | 400~4200mm |
Air consumption | 200L/min |
Cutting length | Max. 4200mm,Min. 400mm |
Cutting width | Max. 135mm |
Cutting angle | 90°,45° |
Cutting profile surface plane | ≤0.10mm |
Cutting angle tolerance | Ra12.5 μm |
Saw blade height max | 300mm*90°;200mm*45° |
Feeding speed | Stepless timing 0~3m/min |
Saw blade specification | φ500mm×4.4mm×φ30mm Z=120 |
Overall Dimension | 5530*1750*1950mm |
Weight | 1850kg |
You may need the following machine if you want start a new factory!
The following is our main supplier brand:
WE ARE NOW EXPORTING TO MORE THAN 35 COUNTRIES ALL OVER THE WORLD
Service of Professional Aluminium Alloy Window Making Machine
ABOUT OUR MACHINE:
1. All our machines are 12 months quality guarantee,lifetime maintance.
2. Engineers available for machinery overseas service.
3. Make specialized solutions for client's requirements.
4. 24-Hour on line by Email , Skype ,WhatsApp or call .
5. Can get spare parts quickly from our Agency or Headquarters.
ABOUT YOUR FACTORY:
1. Give you the suggestions on your factory building.
2.Arrange the machine in your workshop so that can get high efficiency.
3.According to your prodction give you the best plan of full set of machine that you need .
Payment Terms
♦ L/C, 30% deposit by T/T,70% spare payment L/C.
♦ T/T, 30% deposit by T/T,70% spare payment before shipment.
♦ Western Union
Quality Testing
Before delivery ,our engineer must make the Testing for every machine, to make sure that our machines can work with perfect performance !
Packaging Detail: in plastic film and Wooden case
Delivery Detail: 10-20 days once receiving from the 30% deposit
