Aluminium window machine Any Angle Cutting Saw
Model: LJZB-400M
Specification:
lUsed for curtain wall and window of aluminum accurate cutting ,also for UPVC profile . Angle Cutting Saw
l Single head any angle cutting saw with the carbide saw blade, which make sure the high speed and accurate cutting.
l This machine can be installed the size positioning frame, also can added the digital display device according to your requirement, thus can make the locating size more accurate.
l The workbench rotating between the left (-15 °)~90°~(+15°). after the plate retrocession, the workbench can be 0°positioning, then raise and fix the saw blade thus this machine can be used as Routing saw.
Power supply |
380V 50Hz,three phase |
motor power |
1.5Kw |
air pressure |
0.5~0.8MPa |
air consumption |
0.03m³/min |
motor rotation speed |
2800r/min |
Blade feeding speed |
stepless timing 0~3m/min |
cutting angle |
(-15°) ~90°~(+15°) |
Cutting profile surface plane |
≤0.10mm |
Cutting angle tolerance |
Ra12.5 μm |
Cutting width |
165mm,90°MAX |
Cutting height |
123mm,90°,MAX |
saw blade specification |
φ400mm×3.5mm×φ30mm Z=80 |
Overall dimension |
5000×900×1300mm(L×W×H) |
Weight |
600Kg |
You may need the following machine if you want start a new factory!
The following is our main supplier brand:
WE ARE NOW EXPORTING TO MORE THAN 35 COUNTRIES ALL OVER THE WORLD
Packaging Detail: in plastic film and Wooden case
Delivery Detail: 10-20 days once receiving from the 30% deposit
Service of Professional Aluminium Alloy Window Making Machine
ABOUT OUR MACHINE:
1. All our machines are 12 months quality guarantee,lifetime maintance.
2. Engineers available for machinery overseas service.
3. Make specialized solutions for client's requirements.
4. 24-Hour on line by Email , Skype ,WhatsApp or call .
5. Can get spare parts quickly from our Agency or Headquarters.
ABOUT YOUR FACTORY:
1. Give you the suggestions on your factory building.
2.Arrange the machine in your workshop so that can get high efficiency.
3.According to your prodction give you the best plan of full set of machine that you need .
Payment Terms
♦ L/C, 30% deposit by T/T,70% spare payment L/C.
♦ T/T, 30% deposit by T/T,70% spare payment before shipment.
♦ Western Union
Quality Testing
Before delivery ,our engineer must make the Testing for every machine, to make sure that our machines can work with perfect performance !
