Parker Aluminum Window Profile End Milling Machine on Hot Sale
- Qingdao Port China
- T/T Credit Card
You May Like
-
Aluminum Window Profile CNC Cutting Machine CNC Double Mitre Saw Cutting Machine
-
Aluminum Window Machine/Corner Connector Cutting Machine/Aluminum Window Corner Key Cutting Saw
-
Double Mitre Saw Aluminium Saw Cutting Machines-aluminum Double Head Mitre Saw/aluminium Profile Cutting Machine-PARKER
-
Aluminum Window Machine CNC Aluminum Profile Cutting Center
-
Parker Machine A8-500 for Aluminum Profile Cutting Saw With CNC
-
Automatic CNC Double Head Cutting Saw For Aluminum
Product Details
| Brand Name | PARKER |
Product Description
Aluminum window Profile End Milling Machine
Features
- Different from other end milling machine, and suitable for various profiles. It also has a special design for the curtain wall profile.
- Convenient tool adjustment to meet different processing requirement. There has a adjust gauge so it is more exactly for adjusting.
- Clamp one time can process several profiles, which increased the processing efficiency.
- Need not ordering tools when process various profiles, thus can decrease cost and save time.
- Large tool diameter, high milling speed and good processing result.
Our machine is specially designed with safe guards, and they clip the profiles tight, even when electricity is cut off suddenly. So it can ensure the operators’ safety.
Parameter
Voltage: ..............................................................................380V 50HZ
Motor Power: ...................................................................2.2KW
Motor adjusted travel:.................................................0-80mm
Supporting profile operating platform:.................0-1050mm
Supporting profile operating platform size:........530X320mm
Air pressure: ....................................................................0.5-0.8MPa
Blade specification: ........................................................Φ350xΦ30x3.2Z=100
........................................................Φ250xΦ32x6.5 Z=40
Rotary speed:.....................................................................2800r/min
Surface Harshness: ........................................................Ra12.5 µ m
Overall dimension: ...........................................................2700mmX1250mmX1900mm
Weight: .................................................................................1000KG
1. One year warranty time, we can repair and replace parts for free in one year.
2.Technical support in 24 hours online, TM, Skype, E-mail, solving the relative questions in time.
3. Free maintenance service.
4. Free training course at our factory with professional engineers.
5. We provide the consumable parts at agent price when you need replacement.
6. Engineer available overseas.
1. When can we arrange shipment?
We usually arrange shipment in 15 days after getting deposit, but customized machines should be more than 25 days.
2. What to do if you get problems with the machine?
a. We will send you free spare parts if your machines are in guarantee time.
b. We can send our engineers to repair your machines.
Parker Machinery is a manufacturer of high performance window door curtain wall processing machines and insulating glass producing equipment. Parker prides itself on manufacturing the high-qualified and advanced window door equipment in the world. Within over ten years development since 2003, their always primary goal is to create value for their customers, by continuously striving to achieve the highest combination of efficiency and accuracy, combined with cost-effectiveness. The other core concept of parker is to develop with the world. They follow and even lead the manufacturing trend from single machine auto-produce to intelligent production line. They are devoted to provide a series of projects and complete services for window-door solutions. On the basis of the perfect performance in domestic market, Parker also set the aim of a world famous window door processing equipment supplier. Now their equipments and services has been widely accepted by oversea customers from over 50 countries like Canada, Australia, India, Russia, Mongolia , Brazil, Vietnam, USA, England, South Africa and so on.
