New type three axis PVC UPVC Plastic window automatic water slot mill machinery
- 100 Set / Sets per Month
- Qingdao Shanghai Guangzhou
- T/T Credit Card
You May Like
-
UPVC PVC window door portable corner cleaning tools
-
UPVC window door processing machine tools Manual PVC window corner cleaning machine
-
UPVC PVC portable manual window cleaning machine
-
Electric portable PVC window door cleaning tools
-
Portable electric Plastic PVC door window hand cleaning tools for cleaning corner and surface
-
Portable manual Plastic UPVC window door surface cleaning machine
Product Details
Brand Name | Better | Model Number | SCX01-3 |
Product Description
New type three axis PVC UPVC Plastic window automatic water slot mill machinery
New type automatic three axis water groove/slot milling machine for PVC/UPVC/Plastic/Vinyl window door (Model:SCX01-3)
Brief description
This machine is used for processing various water grooves/slots (or say drain holes) and air pressure balance grooves/slots, it is for making PVC/UPVC/Plastic/Vinyl window door production.
Features
1).Full design with high rigidity, processing beautiful water slot, high appearance quality.
2).Automatic cutter changer on the under head, one time clamp to finish water slots processing
3).High efficiency, suitable for mass production
4).Special automatic pneumatic feeding system, feeding speed adjustable.No need special maintenance, high milling quality.
5).Easier adjustment for the cutter location to meet different kinds of profiles.
6).Water slot milling length adjustable within 100mm, wide adaptability.
7).Adopt linear bearing motion to ensure the processing precision.
8).Milling all kinds of water slots and air pressure balance groove.
Friendly note
We have new type Model SCX01-3 and common type Model SCX01-3.
Parameters | |
Model | SCX01-3 |
Power supply | 220V/50Hz or as required |
Input power | 1.14kw |
Working air pressure | 0.5~0.8Mpa |
Rotational speed | 25000r/min |
Air consumption | 30L/min |
Max. groove length | 100mm |
Max. groove depth | 40mm |
Milling cutter diameter | Ø4mm, Ø5mm |
Overall dimensions (LxWxH) | 1200x1200x1800mm |
Net weight (about) | 200kg |
Main parts brand name | |
Electrical button and switcher | Schneider (France brand) |
Standard accessory | |
Certificate | 1 piece |
Complete tooling | 1 set |
Operation manual | 1 piece |
New type Model SCX01-3 pictures
Common Model SCX01-3 pictures
Other related PVC/UPVC/Plastic/Vinyl window door milling machine models
Related PVC/UPVC/Plastic/Vinyl window door production workshop layout
Our company workshop and machines certificates
Our machines in foreign customer workshop
