Hema 9700 Gradient PCR Pcr Machine

 Hema 9700 Gradient PCR

Instruction:

 Hema9700 gradient gradient PCR instrument module can be up to 12 different annealing temperature of PCR reactions simultaneously in the gradient module can be realized on the temperature gradient and

Adjustment of parameters such as the width of the gradient, 12 freely programmable temperature gradient annealing temperature to achieve different samples while thermal cycling. Only an experiment can determine whether a particular system corresponding optimal annealing temperatures. So that in a short time optimization of PCR experiments, greatly improving the efficiency of PCR research. Product integration of today's first at home and abroadadvanced semiconductor technology (Peltier-Based), imported core parts, to ensure that the rate of amplification products, the reliability of the analysis results.

Feature

1, The most advanced Peltier-Based Semiconductor Technology;

2, Convenient and flexible module replacement device, easy to replace the required modules;

3, High-resolution large LCD color display;

4, Intuitive, user-friendly interface, programming is simple and quick;

5, With power and memory function;

6, Low noise, low power consumption, long life;

Techinical Parameter

1 Sample Plate:Standard module:  96X0.2ml+77X0.5ml combined module;

 384 well module(option).Fast and easy to change the module without tools.

2 Temperature range: 0C-100C

3 Temperature raise rate: >= 4.0C /s

4 Temperature down rate:>=3.5C/s

5 Temperature uniformity :<=+-0.2C

6 Temperature accuracy:<=+-0.2C

7 Temperature gradient range: 30-100C

8 Width of the temperature gradient: 1-30C

9 Heat lid temperature :2-110C(adjustable). Pressure of the lid is also adjustable, and    with pressure indicator.

10 Max user programs:200

11 Max cycles: 99

12 Visual interface: 5.7” large TFT color screed with LED backlight and Chinese operating interface, with 640X480 resolution,visual interface for processing status and parameter displaying.

13 Communication port: USB 2.0,  let one PC control the running of 1-128 PCR.Red LED indicator on the terminal show the status of the communication port.USB line is EMC capable. May down load user program directly from PC to PCR via USB port.Excel table data exchange between PC and PCR

14 Program in pocket : may set up, edit, save and copy user program on U disk.Data and file with CRC check code, ensure the data safety and security.Enough space for extend in the file and table.

15 Other features: Time step increasing/step decreasing function for long chain (over 450nm)Chain reaction.Temperature step increasing/step decreasing function for reaction seeking research.
