Home > Products > Analytical instruments > FTIR920 Fourier Transform Infrared Spectrometer
FTIR920 Fourier Transform Infrared Spectrometer
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Brand Name | JINGTUO-S | Place of Origin | Shaanxi, China | |
| Model Number | FTIR920 |
Product Description
Introduction:
FTIR920 Fourier Transform Infrared Spectrometer with wide application field, can be used for pharmaceutical, gemstone testing, coal dust, free silica detection, optical coating, plastics, rubber, viscous liquid, paint, quartz glass hydroxyl content analysis, new materials, additive, cosmetic, fiber, silicon carbon and oxygen content and so on analysis and test.
Features:
Spectral resolution: suitable for solid, liquid and gaseous samples;
Well Stability: the use of the new Michelson self compensating optical system, to avoid the use of the traditional three plane right angle prism and dynamic correction.
Strong Scalability: large sample space, to meet all the needs of FTIR spectral analysis of the sample operation
High precision: ultra high sensitivity design, configuration DLATGS greenhouse detector, without liquid nitrogen can also be convenient and safe detection of samples;
Powerful Software : easy to operate, easy to understand.
Convenient debugging: the energy of the interferometer can be adjusted without opening the cover.
Easy maintenance: no need to open the host can be replaced by desiccant.
Technical parameters:
Wavelength range:7800-375cm-1
Resolution :better than 1.0cm-1
scanning speed:2mm/s,
SNR(Signal to Noise Ratio):better than 15,000:1
linearity:≤0.1%T
Wave number precision:0.01 cm-1
beam splitter:multilayer coating KBr
Aperture ratio:1/3.2
Detector :Imported low noise DLATGS
Light source: imported long life high intensity air cooled ceramic infrared light source
Interferometer: automatic correction
Cleaning function: Yes
Frequency parameter (data acquisition):He-Ne Laser
Sample beam :10mm dia
Beam diameter:30mm
Jet port: optional
Data transmission:USB2.0
Sample room :200*260*160(mm)
Dimension :590*390*190(mm)
working voltage:90-230V AC 12V DC 40W
operating system:Windows 98/2000/XP/Vista 32-bit
Weight :24kg
environment temperature:15-28℃
environment humidity:Below 65%, no condensation
Dear customer, We ,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history . Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing, bioscience,medical apparatus and instruments,internet technology and some frontier science. Through a long-time development,we own a national resources system of various professional talents , abundant supply for various components &parts and special materials, full producing &processing equipments , strong Technological standardization and a complete quality assurance system. If you need OEM or ODM in manufacturing ,scientific research , market development and or you want to build your own brand in your country, it’s our honor to cooperate with you.In this way ,we have developed many products for our customers from the USA, Europe and South Africa and got good feedback on Alibaba We firmly believe that science and technology is no boundaries Our mission is to make every effort to contribute to all humanity.
|
