Help CenterBW-930A Helium Leak Detector
Related Products
-
GDYQ-100M Multi-parameter Fast Food Safety AnalyzerUS$ 6,700 - 8,780MOQ: 1 Set -
HBR-24A Biological Sample HomogenizerUS$ 7,000 - 10,000MOQ: 1 Unit
-
UVRaman100A UV Resonance Raman Spectroscopy SystemUS$ 240,000 - 300,000MOQ: 1 Set
-
TD-2300 True Density Analyzer ( Gas Expansion Method )US$ 36,500 - 39,000MOQ: 1 Unit
-
KN-COD12A COD Digestion InstrumentUS$ 1,600 - 2,000MOQ: 1 Unit
Introduction :
1. The core components of molecular pump, using the imported special molecular pump leak detector.
2. The AD amplifier, effectively reduce the noise of the leak detector itself, improve the sensitivity of the leak detector.
3. 180 degrees of inhomogeneous magnetic field of the mass spectrum chamber design, focusing accuracy, high sensitivity.
4. High voltage leak detection mouth, can leak detection rate range wide, big small leakage can be checked.
5. Ion source filament with yttrium oxide iridium filament, long life and high sensitivity.
6. Leak detection conditions unique three screen switch, more abundant information, leak detection more convenient.
7. Has the function of rapid pure helium and quick response.A key to leak detection state reset.
8. Automatic LCD touch screen display, the realization of the intelligent automation, convenient operation, simple and reliable.
Features:
1. Import molecular pump
2. Domestic mechanical pump
3. Customized special solenoid valve leak detector
4. The built-in standard leak
5.Import amplifier
6. Special modules using mass spectrometry
7. Iridium wire (outside of yttrium oxide coated) ion source
8. LCD touch color screen
Technical parameters:
1. Minimum leakage rate:5×10-12Pa•m3/s
2. Leakage rate range:1×10-4—1×10-12Pa•m3/s
3. Starting time:≤3min
4. Response time :≤1.0s
5. The highest pressure of leak detection mouth:300Pa
6. Mechanical pump pumping speed:1.1L/s
7. Power supply :220V,50Hz,single phase,10A
8. work environment:5-40℃
9. relative humidity:≤80%
10. Dimension :550(W)*420(D)*700(H)
11. Weight :65kg
