Home > Products > Analytical instruments > SFJ-261C Helium Leak Detector
SFJ-261C Helium Leak Detector
- shenzhen
- T/T Credit Card
You May Like
Product Details
| Brand Name | WY | Place of Origin | Shaanxi, China | |
| Model Number | SFJ-261C |
Product Description
Introduction:
SFJ-261 helium mass spectrometer leak detector is introduced advanced foreign technology
and our work experience of mass spectrometer. The main parts are all imported. Stable and
reliable system guarantee the reliable performance. High sensitivity and easily operation make
double-filament switching, zeroing, adjusting and ranging switch are all automatically, which
has reached the international advanced level.
Features:
Dual-filament automatically switch
Portable product
Touch-screen operation
Auto-calibration feature
Range automatic switching
Password security
Technical parameters:
Minimum detectable helium leak | Test range | Start –up time | Response time | Maximum inlet test pressure | Terminal vacuum | Display | Host Size | Weight |
5×10-12Pa·m3/s | 1×10-3 a·m3/s-1 ×10-12 Pa·m3/s | 3Min | 1S | 1000Pa | 5×10-4Pa | Touch-TFT display | 560(W)×420(D) ×280(h) | 43kg |
It can be matched with cart.
Standard with 2.5m, customized according to the demands of clients.
Key component
Parts name | model | manufacturer | Producing area |
High vacuum pump | 070 | Leybold | German |
Primary pump | GHD030 | ULVAC | Japan |
Electromagnetic valve | 0256 | Burkert | German |
amplifier | 549 | AD | USA |
Application Fields
Vacuum Industries:
Vacuum system, Pressure container, Valve and Coating system, Vacuum apparatus, Vacuum furnace, and fire extinguisher;
Refrigeration Industries:
Condenser, Vaporizer, Connectingpipe, Valve, Waterlank, Radiator, Low-temperature pump and Low-temperature storage tank;
Semi-condustries:
Semi-conductor(Wafer) equipment, Front channel, back channel, Integrated circuit, Photo-electronic component, Battery and Electric beam welding equipment:
Scientific researches:
Research Institute, high-energy Physics and Nuclear energy research Accelerator, Beam ray and in-phase radiation light source, Experiment, Surface analysis system and Space simulation system;
Aviation and Spaceflight:
Airplance airfoil oil tank, inertial navigation components. Aviation and Airplane parts
Dear customer:
We ,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history .
Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing, bioscience,medical apparatus and instruments,internet technology and some frontier science.
Through a long-time development,we own a national resources system of various professional talents , abundant supply for various components &parts and special materials, full producing &processing equipments , strong Technological standardization and a complete quality assurance system.
If you need OEM or ODM in manufacturing ,scientific research , market development and or you want to build your own brand in your country, it’s our honor to cooperate with you.In this way ,we have developed many products for our customers from the USA, Europe and South Africa and got good feedback on Alibaba.
We firmly believe that science and technology is no boundaries.
Our mission is to make every effort to contribute to all humanity.
