QL- BS1000B Almighty Precise Elemental Analyzer

QL- BS1000B Almighty precise elemental analyzer

        The first use of a continuous wavelength tunable light source technology to improve the instrument's scope of application and accuracy of analytical results . As long as there are elements of photometric methods , you can use the instrument for analysis , which can be applied to black and non-ferrous metals and their alloys and other materials, silicon , manganese, phosphorus, nickel , chromium , copper and other elements of the content of meet casting, metallurgy, machinery , chemical industry in the blast furnace , finished , incoming testing and other aspects of multi-element analysis of various materials needs .

Technical parameters:
 wavelength range :400-800nm ( wavelength continuously adjustable )
Absorbance range :0-1 .999 A
concentration range :0.000 - 99.99 % Automatic gearshift display
Display: 1 inch digital display tube
Wavelength Accuracy : ± 3nm
Data storage : EEPROM inside the machine power data stored for 10 years
Power: AC 220V ± 10%, 50Hz ± 5%
Power consumption : ≤ 45W
Weight : ≤ 15kg

Main features:
1.domestic first elemental analyzer tunable wavelength light source system
2.products not only wavelength continuously adjustable , and a substantial increase in accuracy from conventional elemental analyzer wavelength error is 20nm ( preferably ± 5nm) to the present 3nm, which can make products in the expanding range of applications at the same time , improve the analysis and detection of accuracy.

3.using MCU program control and data processing. Can quickly and accurately measure the many elements in the steel and non-ferrous metal mass fraction , high degree of automation , accurate and reliable quantitative increase in liquid , reagents less so to improve the accuracy and precision of the analysis , can directly display quality scores and print.
4.using cold light source patented technology, imported optical components, self-calibration zero and full scale ;
5.single-chip microcomputer control , shortcut keys , quick replacement of different thickness cuvette can store nine curves ;
6.outside dissolving , easy to operate , no valves and piping aging and prolong life.
