Factory Direct Sale Low Voltage Pvc Insulated Aluminum Wire Made in China
- Tianjin port Qing dao port Shang hai port
- T/T Credit Card
You May Like
-
Hotsell 4mm 6mm Flexible Cooper Electric Wire and Cable Pvc Insulation Electrical Wire and Cable 10mm With CE Certificate
-
450/750V Electrical Cable/electrial Wire/power Wire 10mm for Housing
-
CE Approved 6242Y 2*2.5mm+1.5mm Twins and Earth Flat Cable
-
China Supplier High Quality Copper PVC Insulated House Wring 6 sq mm Cable With CE Certificate
-
300/500V Pvc Insulated 3 Core 1.5mm 4mm Flexible Cable
-
0.75mm 1.0mm 1.5mm 2.5mm 4mm 6mm 10mm Copper-core PVC Insulated PVC Sheathed Flat Wire and Cable
Product Details
| Brand Name | REN DA | Place of Origin | Hebei, China | |
| Model Number | BLV | Type | Insulated | |
| Insulation Material | PVC | |||
| Conductor Type | Solid |
Product Description
Factory price 450/750V pvc insulated single core aluminum electrical wire made in China
450v/750v PVC insulated wire
1.BLV
2. Application
PVC insulated wires is suitable for laying at the fixed places. It is widely used in connecting of power device, lighting, daily electrical appliance, instrument etc. with AC rated voltage up to and including 450/750V(U0/U).
3. Standard
The product implement the standards GB/T5023, equivalent to IEC60227. And it can also be made complying with ASTM, DIN, BS standards etc. In addition, we can design and manufacture the products as the requirements of customers.
4. Brief construction
1) Conductor: Copper or aluminium, Solid
2) Insulation: PVC
3) Number of cores: Single core
4) Other special characteristics: Design and manufacture according to the requirements of customers.
5. Service performance
1) Rated voltage: 450/750V
2) Long-term working temperature: not be higher than 70°C
3) When laying the cable, the ambient temperature should not lower than 0°C
4) Minimum bending radius: Bending radius≥4D as cable overall diameter≤25mm; Bending radius≥6D as cable overall diameter>25mm.
(6) Specification and technical data
Type | Rated Voltage (V) | Cores | Nominal Sectional Area (mm2) |
60227IEC01(BV) | 450/750 | 1 | 1.5-400 |
60227IEC02(RV) | 450/750 | 1 | 1.5-240 |
60227IEC05(BV) | 300/500 | 1 | 0.5-1 |
60227IEC06(RV) | 300/500 | 1 | 0.5-1 |
60227IEC07(BV-90) | 300/500 | 1 | 0.5-2.5 |
60227IEC08(RV-90) | 300/500 | 1 | 0.5-2.5 |
60227IEC10(BVV) | 300/500 | 2-5 | 1.5-35 |
60227IEC42(RVB) | 300/300 | 2 | 0.5-0.75 |
60227IEC52(RVV) | 300/300 | 2-3 | 0.5-0.75 |
60227IEC53(RVV) | 300/500 | 2-5 | 0.75-2.5 |
60227IEC56(RVV-90) | 300/300 | 2-3 | 0.5-0.75 |
60227IEC57(RVV-90) | 300/500 | 2-5 | 0.75-2.5 |
BV | 300/500 | 1 | 0.75-1 |
BLV | 450/750 | 1 | 2.5-400 |
BVR | 450/750 | 1 | 2.5-70 |
BVV | 300/500 | 1 | 0.75-10 |
BLVV | 300/500 | 1 | 2.5-10 |
BVVB | 300/500 | 2-3 | 0.75-10 |
BLVVB | 300/500 | 2-3 | 2.5-10 |
RVS | 300/300 | 2 | 0.5-0.75 |
Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billion Chinese Yuan. Now there are more than 800 employers in our company, among which more than 150 are technicians. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects.
Products: XLPE insulating power cables with voltage up to 35kV, PVC insulated power cables, mining cable, general rubber sheathed flexible cable, Submersible oil pump cable, locomotive
vehicle cables, elevator cable,shipboard cable, nuclear station cables, pre-fabricated branch cables, ABC cables, control cables, special cables, the motor winding connecting conductors, aluminum stranded conductor (AAC) and aluminum stranded steel-core reinforced conductor (ACSR) so on.
We are JV with Furukawa(Japanese company) for rubber serial cable (minding cables, welding cables.submersible oil pump cables, .)and also JV with Riken(Japanese company) for elevator cables. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria, South Africa,Congo, Middle East and Southeast Asia countries and so on.
1. 22 years production experience and 13 years export experience .
2.high-end Machinery and equipment for high quality cable .
3.manufacture various of cable :power cable,control cable,abc cable,submersible oil pump cable,rubber cable,elevator cable,electric cable...
4. products certification :UL,CE,BV,TUV,KEMA,PSB,SABS,ABS,NK,LR,KR,GL,DNV:
system ceryification:ISO9001,ISO14001,OHSAS18001
5.our product sells all over the world and has the good reputation.
fessional teamwork service for you actively.
7.quick solution and long time online time waiting for your inquiry.
8.rapid delivery and feedback.
9.we can do that you except.
(1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, pleasecall us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freightcharge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account or prepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
(5)What cables does Hua Tong manufature?XLPE insulating power cables with voltage up to 35kV, PVC insulated power cables, mining cable, general rubber sheathed flexible cable, Submersible oil pump cable, locomotive vehicle cables, elevator cable,shipboard cable, nuclear station cables, prefabricated branch cables, ABC cables, control cables, special cables, the motor winding connecting conductors, aluminum stranded conductor (AAC) and aluminum stranded steel-core reinforced conductor (ACSR) so on.
(6). Which payment terms do you accept?
A: The payment term varies with different price level and total value of every contract.
The following are most common terms:
a.100% TT advance for small amount orders.
b.30% T/T down payment, balance payment negotiable accordingly.
