TK6913 cnc horizontal boring machine/cnc horizontal borer
Such TK6913 cnc floor type horizontal boring milling machine/cnc horizontal borer has following features:
This machine is applies to the coarse and fine processing as well as drilling and reaming processing of surface and hole for large, heavy and over heavy complex components.
It is suitable for general machinery manufacturing industry, especially for single pieces and small batch production of high precision and complex components.
It has features of reducing manufacture number of process equipment and shortening production preparation period. The machine can complete the processing of milling, boring, turning, drilling and hole boring only in condition that workpiece is prepared on machine.
This machine uses circular interpolation process (x, y coordinate axes) as well as small diameter milling cutter which can process any plane curve type surface.
The adoption contouring control method for milling of inclined plane, square plane and big hole end plane narrowed operating space, improved production efficiency and relieve labor intensity.
This machine is equipped with high precision rotary work table and square-edge milling head and other functional components which can complete the processing of pentahedron.
Specifications |
Unit |
Parameter |
Spindle bore diameter |
|
Φ130 |
Spindle taper |
|
Metric 80# |
Spindle speed (stepless) |
r/min |
4~800 |
Range of spindle speed |
mm/min |
4~200/0.05~8 250~800/0.01~2 |
Travel of spindle (Z - axis travel) |
mm |
900 |
Between spindle center and table surface |
mm |
Max.1500 Min.0 |
Max. spindle axial thrust |
N |
31360 |
Max, spindle torque |
Nm |
4900 |
Travel of headstock (Y - axis travel) |
mm |
1500 |
Feed range (stepless) |
mm/min |
4~200/0.05~8 250~800/0.01~2 |
Travel of front column(X - axis travel) |
mm |
6000 |
Maximum loading capacity |
t/m2 |
15 |
Power of main motor |
kW |
22 |
Feed motor power |
kW |
7.5 |
Overall dimensions (LxWxH) |
mm |
8000x1470x4115 |
Weight of machine |
t |
40 |
S/N |
Name |
Part No. (specification) |
Quantity |
1 |
Radial tool post |
T6216-90001 |
1 |
2 |
Jaw |
T6216-90002 |
1 |
3 |
Socket wrench (S=46) |
T6216A-90350 |
1 |
4 |
Socket wrench (S=75) |
T6216A-90351 |
2 |
5 |
Small adjusting shaft of spindle bearing nut |
T6216-90355 |
1 |
