China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine

China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine thumbnail-1
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine thumbnail-2
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine thumbnail-3
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine thumbnail-4
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine thumbnail-5
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine photo-1
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine photo-2
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine photo-3
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine photo-4
China Manufactory Hotsale Horizontal Cut and Wrap Wrapping Machine photo-5
US$ 8000 - 15000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
hennopack
Place of Origin:
China
Model Number:
MH201
Contact Supplier Request Quote Chat Now
Shenzhen Henno Packaging Technology Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen port,china
Delivery Detail:
25 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name hennopack
Place of Origin China
Model Number MH201
Certification ce,ul,iso9001
After-sales Service Provided Engineers available to service machinery overseas
Weight 660kg
Dimension(L*W*H) 4100mm*1600mm*1450mm
Voltage 3PH 380V 50Hz/60Hz
Power 2.0KW
Application Beverage, Chemical, Machinery & Hardware, Medical
Condition New
Automatic Grade Automatic
Driven Type Electric
Packaging Material Plastic
Packaging Type Other, Film, stretch film orbital wrapper
China manufactory hotsale horizontal cut and wrap wrapping machine

Description of horizontal cut and wrap wrapping machine:

Product Application

This is semiauto orbital stretch film wrapper and orbital packging machine with automatic material cutting and sealing device specialized for packing horizontal objects such as sheets, aluminum profile, doors, Floor board, window, furniture… the wrapped package is well-protected & sealed & looks more tidy. The machine can be connecting to the packing line for automatically wrapping.

SPECIFICATIONS FOR ORBITAL SPIRAL STRETCH WRAPPER
MH-200
MH-300
MH-400
Object size:
Length:>1500mm
Package OD: 100-200mm
Weight:10-100kg
Length:>1500mm
Package OD: 100-300mm
Weight:10-300kg
Length:>1500mm
Package OD: 100-400mm
Weight:10-500kg
Air Supply:



5~8kgf/cm2
5~8kgf/cm2
5~8kgf/cm2
Wrapping Speed:
5～18m/min
5～15m/min
5～15m/min
Packaging machinal
LLDPE stretch film
Width: 50-200mm
OD: 100-200mm
ID: 50mm
(Let me know, if you need another material)
LLDPE stretch film
Width: 100-200mm
OD: 100-200mm
ID: 50mm
(Let me know, if you need another material)
LLDPE stretch film
Width: 100-250mm
OD: 100-250mm
ID: 50mm
(Let me know, if you need another material)
Air supply
5~8kgf/cm2
5~8kgf/cm2
5~8kgf/cm2
Ring speed
App.10-80r/min
App.10-60r/min
App.10-60r/min
In feeding conveyor
2000mm L×800mmW
2000mm L×1400mmW
2000mm L×1800mmW
Out feeding conveyor
2000mm L×800mmW
2000mm L×1400mmW
2000mm L×1800mmW
Application
Panel, wooden, door, aluminum, profile, board,tube, pipe, tunnel, section
Panel, wooden, door, aluminum, profile, board,tube, pipe, tunnel,bundle
Panel, wooden, door, aluminum, profile, board,tube, pipe, tunnel,bundle
Operation

a) Place the products onto the orbital stretch wrap machine in-feeding conveyor.
b) Moving the product to wrapping position automatically while sensors detect it
c) Press down device presses the package automatically.
d) Products stop automatically while it at the sealing position.
e) Feeding and cutting packing material automatically.
f) Products go through the wrapper for automatic sealing and wrapping.
g) Place the reinforcing wraps to the tail end of the product.
h) Unloading the packed package.
i) End for circle
