High efficiency Hard Turning Bearing steel Wind turbine bearing With Halnn manufacturer CBN Cutting Tool full form
1. Halnn Tools CBN Cutting Tool full form Hard Turning Bearing steel Wind turbine bearing
Choose a series of grades such as Halnn Tools cubic boron nitride tool BN-S20, which can efficiently process bearings, effectively improve processing efficiency and reduce production costs.
As a leader in professional hard material processing tools, Halnn Tools is dedicated to the exploration and research of cubic boron nitride tools, so that the world no longer has difficult materials to process. In recent years, Halnn Tools has continuously provided high-quality, high-performance, high-efficiency tool products for high-speed, precision machining and other cutting requirements in the field of high-hardness and difficult-to-machine materials with its long-term technical strength and cutting-edge technology development capabilities. , has a number of tool products that customers trust.
2. Characteristics of CBN Cutting Tool
Insert Grade |
Suited Materials |
Machining Type |
Typical Application |
BN-S20 |
Hardened Steel, Heat and abrasive resistant steel, High manganese steel |
Roughing, Semi-Finishing |
HSS Rolls, Ball Screw, Wind Power Bearings |
BN-H11 |
Hardened Steel |
Semi-Finishing, Finishing |
Bearings, Gears, Gear Shaft, Hardened Mold |
BN-H20 |
Hardened steel, other materials of difficult to machine |
Semi-Finishing, Finishing |
Hardened Steel Gears, Mold,ect |
BN-H10 |
Hardened Steel, high strength cast iron |
Finishing |
Bearings, Gears, Gear Shaft, High hardness component |
BN-H21 |
Hardened Steel |
Finishing |
Bearings, Gears, Gear Shaft, Mold,ect. |
3. Advantages of Halnn CBN Cutting Tool
As an important part supporting the mechanical rotating body and ensuring its rotation accuracy, the bearing is widely used in major machinery industries. With the continuous advancement of modern technology, the requirements for bearings are gradually improved, and in order to meet increasingly diverse bearing characteristics, The tool industry is also constantly developing high-precision, high-efficiency, high-quality tool materials. It is very important to select the tool material when machining the bearing. Choose a series of grades such as Halnn super-hard cubic boron nitride tool BN-S20, which can efficiently process the bearing, effectively improve its processing efficiency and reduce production cost.
4.Application Case
BN-S200 Solid CBN Insert processing bearings | |||
Machining Part:Slewing bearing ring |
|
||
Workpiece Hardness:HRC 47~55 | |||
Cutting Type:Dry Cutting | |||
Machining Materials:42CrMo4 | |||
Inserts Grade:BN-S20 | |||
Cutting Parameters: ap=0.5mm，Fr=0.45mm/r，Vc=110m/min。 | |||
Testing Performance | |||
Inserts Materials |
Linear Speed (m/min) |
Lifetime/edge |
Roughness |
Halnn BN-S20 |
110 |
8 |
Ra0.8 |
Ceramic Inserts |
90 |
1 |
Ra1.6 |
5.Image
6. Contact us
If you have another question, pls feel free to contact us as below:
Contact us | |
Joanan@halnntools.com |
|
+86 17537165259 |
|
Skype |
Joanna Guo |
+86 17537165259 |
|
