Help CenterDiamond Bruting Wheel, Ceramic Diamond Wheel for Gemstones
Related Products
-
Bruting and Grinding Natural Diamond Vitrified Bond WheelUS$ 0.1 - 0.5MOQ: 1 Piece -
Bruting and Girdling Natural Diamond,Polishing Natural DiamondUS$ 0.1 - 0.5MOQ: 1 Piece
-
CNC Tool Grinding Wheel,Flute Grinding Wheel, End Mill Grinding/Burr Grinding WheelUS$ 0.1 - 0.5MOQ: 1 Piece
-
Resin Bond Grinding Wheels for CNC Tool Grinder,CNC Machine Grinding WheelsUS$ 0.1 - 0.5MOQ: 1 Piece
-
Vitrified Bond Double Side Face CBN Grinding DiscUS$ 0.1 - 0.5MOQ: 1 Piece
Shape Material Grit size Application
1A1 SDC 180 180*10*32*10 For tools
1A1 SDC 320# 180*6*32*10 For Tungsten steel
11A2 SDC 100# 125*30*32*10*10 For Tungsten steel
11A2 SDC 180# 100*40*32*5*5 For Tungsten steel
1A1 SDC 150/200# 200*5/20*32*5/10 Grinding magnetic core
Punch machine SDC 180# 100*25*25.4*3*5 Punch machine
1A1 SDC 180# 50*3*10*5 Grinding magnetic core
1A1 SDC 300/600# 200*23*60*17.5*10 PCB
11A2 SDC 1500# 100*32*20*5*10 Universal grinding machines
3A1 SDC 1000# 135*15*31.75*2*10 PCB micro drill
11A2 SDC 150# 125*32*32*5*5 Wordcut tools
1A1 CBN 400# 205*12*31.75*8/10 Chrome steel cutting tools
If you need any products, do not hesitate to contact
Skype:Annawng
WhatsApp:+8615617785923
@moresuperhard.com
We provide the standard GB / T6409.2-1996 resin bonding agent superhard material grinding wheel, diameter range: ф20 ~ 700mm, grinding wheel thickness: 5 ~ 300mm, abrasive grain size: 60/70 ~ W3.5. And according to user requirements design and manufacture of non-standard abrasive.
1. Grinding efficiency, while grinding wheel consumption is relatively slow;
2. Self-sharpening is good, the grinding heat is small, not easy to block, reducing the phenomenon of work burn when grinding;
3. Wheel has a certain elasticity, is conducive to improving the surface roughness of the workpiece, mainly used for fine grinding, semi-fine grinding, knife grinding, polishing and other processes;
4. Diamond resin wheel is low temperature curing, short production cycle, equipment and supply process is relatively simple; due to the resin with mobility, easy to shape the surface of the grinding wheel.
