Wide Belt 3 Heads Calibrating Sander Machine for Making Plywood
US$ 12000 - 20000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
METROMACH
Place of Origin:
China
Model Number:
SR3A-I
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao, China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Woodworking Wide Belt Sander Machine for Making PlywoodUS$ 12000 - 20000MOQ: 1 Set -
Two Heads Roll Feed Wide Belt Sander MachineUS$ 12000 - 20000MOQ: 1 Set
-
Woodworking Three Heads Heavy Duty Calibrate Sander MachineUS$ 20000 - 40000MOQ: 1 Set
-
Plywood Wide Belt Heavy Duty Sander MachineUS$ 10000 - 23000MOQ: 1 Set
-
Plywood Double Sides Wide Belt Sander MachineUS$ 20000 - 30000MOQ: 1 Set
Brand Name
METROMACH
Place of Origin
China
Model Number
SR3A-I
Certification
CE, ISO,FDA
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
1 year
Weight
9800KG
Dimension(L*W*H)
3140X2770x2440mm
Condition
New
Voltage
380V
Power(W)
79.5KW
Type
Sander
1. Main features:
This machine is suitable for the thickness setting, light sanding and fine polishing of the small
type wood board, veneer, chipboard, fiberboard, middle dense board, aminatedboard, and variety
of sheet materiaks for the funiture factory and the board mill.
The roller's diameter is much bigger and the rollers have been run-balanced precisely, which makes running smoothly and improves the sanding power.
2. Main technical specifications:
| BSG1313R-R-P | |
| Sanding width(Max) | 1300mm |
| Sanding Thickness | 2.5-110mm |
| Sanding Length | >780mm |
| Abrasive belt dimension | 1330X2620mm |
| Feed Speed | 20-50,50-80m/min |
| Abrasive belt Speed | 20,20,24m/s |
| Motor for sanding head #1 | 30kw |
| Motor for sanding head #2 | 22kw |
| Motor for sanding head #3 | 18.5kw |
| Motor for feed | 7.5kw |
| Motor for brush | 0.75kw |
| Motor for lifting | 0.75kw |
| Total Capacity of motors | 79.5kw |
| Power supply | 380v 50Hz |
| Operating pressure | 0.6-0.8MPa |
| Capacity of suction extraction | 7900m³/h |
| Dimension (LxWxH) | 3140X2770x2440mm |
| Net Weight | 9800kgs |
