1. The brief introductions of ZLJ350 coal mine drilling rig
ZLJ series coal mine tunnel drilling rig is mainly used for exploring water, exploring coal,drawing out methane, water injection dust control. The rig can work in various kinds of angles
This drill rig adopts mechanical drive, hydraulic feed with small size, light weight, The rig is reliable and convenient to operate.
2. The specifications of ZLJ350 coal mine drilling rig
Drilling diameter |
50-113mm |
Drill rod caliber |
33.5mm-42mm |
Non-coring bit |
50-89mm |
Core bit |
56-89mm |
Vertical rated speed |
375/214/120 r/min |
Vertical shaft torque rating |
130/230 /400 n.m |
Main shaft angle |
0-360 |
Spindle stroke |
400mm |
System pressure rated |
8mpa |
Feed force |
9kn |
Elevating power |
12kn |
Winch lifting capacity |
7.35kn |
Drum capacity |
26.8m |
Wire rope diameter |
8.85mm |
Oil pump type |
YBC-12/125 |
Motor power |
5.5kw |
Dimension |
1250*640*1265mm |
Total weight |
500kg |
