Help CenterSmall Portable Geological Investigation Soil and Rock Sample Core Drilling Rig Machine
Related Products
-
Light Weight Portable Mountain Geophysical Exploration Drill RigUS$ 1200 - 1300MOQ: 1 Set -
Huaxiamaster Hydraulic Portable Drilling Rig Mountain Drilling Machine for SaleUS$ 1200 - 1300MOQ: 1 Set
-
Diesel/electric Borehole Rotary Tractor Mounted Water Well Drilling RigUS$ 1200 - 1300MOQ: 1 Set
-
Huaxiamaster KQZ-70D Air Pressure and Electricity Joint-action DTH Drilling Rig for SaleUS$ 1200 - 1300MOQ: 1 Set
-
Huaxiamaster KQZ-100 Full Pneumatic DTH Drilling Rig for SaleUS$ 1200 - 1400MOQ: 1 Set
3. Parameters of XYC-200 vehicular drilling rig
XYC-200 vehicular drilling rig | |||
Drilling depth(m) |
30-200 |
||
Drilling diameter(mm) |
300-75 |
||
Drilling Angel(mm) |
90-75 |
||
Spindle rotating speed(r/min) |
64/128/287/557 |
||
Spindle stroke(mm) |
450 |
||
|
Main hoisting capacity (single line)(Kg) |
1600 |
||
|
Main hoisting line capacity (m) |
35 |
||
Hoisting speed(r/s) |
17/35/75/151 |
||
Wireline diameter(mm) |
12.5 |
||
Mast height(mm) |
7000 |
||
Mast effective height(mm) |
6500 |
||
Kelly/active pipe(mm) |
59*53 |
||
Drill rod(mm) |
42/50/60 |
||
Drill rig weight(kg) |
1150 |
||
Power Unit |
Model |
ZS1115 diesel engine |
|
Rated power |
14.7kw/2200rpm |
||
|
BW-160 mud pump |
Rated flow(l/min) |
160 |
|
Rated pressure(mpa) |
1.3 |
||
Driving power(kw) |
5.15 |
||
|
Main machine weight (kg) |
190 |
||
Dimension(mm) |
1110*725*965 |
||
|
Chassis
|
Model |
95hp light truck The 3.3 meter steeplechase double light card |
|
Drive mode |
4*2 |
||
|
Power unit |
Model |
Quanchai 4B2-95C40 |
|
Emission standard |
GB3847-2005,GB17691-2005Ⅳ |
||
Rated power(kw) |
70 |
||
Rotating speed(r/min) |
3200 |
||
