Hydraulic Rubber Hoses, High Pressure Hydraulic Hose, Fiber Reinforced Hydraulic Rubber Hose Wholesaler.
Introduction:
Be suitable to carry hydraulic fluids, such as glycol, mineral oils, emulsion, hydrocarbons, etc.
Detailed Information:
CONSTRUCTION: This hose consists of an inner tube of oil resistant synthetic, rubber, one wire braided reinforcement and an oil and weather resistant synthetic.
Working Temperature: -40℃～+100℃（-40°F~+212°F） rubber cover.
Features:
Parameter：
SAE 100 R6 Fiber Hydraulic Rubber Hose Specifications:
DN | Inches | I .D (mm) | O.D(mm) | Max.W.P | Min. B.P | Min. B.R | |
Min | Max | Max | (Mpa) | (Mpa) | (mm) | ||
5 | 3/16 | 4.4 | 5.2 | 11.9 | 3.4 | 14 | 50 |
6 | 1/4 | 5.9 | 6.9 | 13.5 | 2.8 | 11.2 | 65 |
8 | 5/16 | 7.4 | 8.4 | 15.1 | 2.8 | 11.2 | 80 |
10 | 3/8 | 9.0 | 10.0 | 16.7 | 2.8 | 11.2 | 80 |
13 | 1/2 | 12.1 | 13.3 | 20.6 | 2.8 | 11.2 | 100 |
16 | 5/8 | 15.3 | 16.5 | 23.8 | 2.4 | 9.6 | 125 |
19 | 3/4 | 18.2 | 19.8 | 27.8 | 2.1 | 8.4 | 150 |
Application:
Be suitable to carry hydraulic fluids, such as glycol, mineral oils, emulsion, hydrocarbons, etc.
Dongguan Rener specializes in all kinds of hydraulic hoses and flexible hose assembly solution. Our main products: high pressure rubber hose, Industrial Hose, etc. If you have interested in our High Pressure Hydraulic Hose, please feel free to contact us
