Help CenterOcean Low Pressure Pipeline Hose
Related Products
Petroleum Hose, Ocean Low Pressure Oil Hose, Oil Discharge Hose Supplier
For suction and discharge fuel, crude oil, hot tar , asphalt, gasoline , oil and biofuels.
MEDIA: Apply to transport -20℃ to 121℃ crude oil and petroleum products.Water, oil base mud and cement slurry can also be transported.
W.P.(MAX):Constant Pressure -10Bar(150PSI)
TEMP.MIN~MAX:-20℃ to +121℃
The hose owns double propeties of bearing positive or negative pressure under vacuum degree less than 80 KPa(600mm)and working pressure less than 10MPa.
Ocean low pressure pipeline apply to transport -20℃ to +121℃ crude oil and petroleum products. Water, oil base mud and cement slurry can also be transported. Maximum resistance pressure 10Bar,maximum resistance temperature 121℃.
Parameter:
Ocean low pressure pipeline hose Parameter
in.mm I.D | Mpa(psi) W.P | Basic Length | Max Length | |||
Size | Tolerance | Mpa | Kgf/cm2 | m | Tolerance mm | m |
51 | ±1.2 | 1-10 | 10-100 | 20 | ±200 | 30 |
64 | ±1.5 | 1-10 | 10-100 | 20 | ±200 | 30 |
76 | ±1.5 | 1-10 | 10-100 | 20 | ±200 | 30 |
89 | ±1.5 | 1-10 | 10-100 | 20 | ±200 | 30 |
102 | ±2.0 | 1-10 | 10-100 | 20 | ±200 | 30 |
127 | ±2.0 | 1-10 | 10-100 | 10 | ±120 | 10 |
152 | ±2.0 | 1-10 | 10-100 | 10 | ±120 | 10 |
203 | ±2.5 | 1-10 | 10-100 | 10 | ±120 | 10 |
Choose Dongguan Rener is the leading manufacturer of hydraulic hoses, assemblies, fittings and crimping technology for industrial and hydraulic markets. Our hydraulic hoses mainly include Food Grade Hose, Water Steam Hose, Oil Suction Hose, Compressed Air Hose and other Hose. If you have
interested in our High Pressure Hydraulic Hose, please feel free to contact us
