Wellhead Adjustable Choke Valve 2 9/16" - 3K
2 9/16" - 3K Adjustable Choke Valve API 6A Wellhead Equipment
Introduction of the 2 9/16" Adjustable choke valve
Manual and adjustable choke valve has the following features: The gate and seat are made up of special anti-wear material and they can be used turn over. Therefore, service life can be increased. The valve has high flow capacity because of its big cavity and plunger gate, which make it eliminate vibration and reduce noise during throttling. The valve is only used for throttling, not used for sealing
Features of the Adjustable Choke Valve
* The flow regulation of adjustable Choke valve is readable from ruler;
* It insert hard alloy insert into nipple, and used the special tungsten carbide metallic materials to manfucture the valve rod, conehead and plunger and pore plate.
* Longer service life of the adjustable valve;
*The tops of valve seat and valve rod are made by carboloy metal when ensures fine corrosion resistance and erosion resistance;
*The valve is of good flowing property of liquid, slight vibration, low noise by using the valve rod cylindrical on the top
Detailied specification of the 2 1/16" adjustable choke valve and 2 9/16" adjustable choke valve
1 | CHOKE,ADJUST,ASSY2-1/16"-3K,FLG CONN | Description : CHOKE, ADJUSTABLE ASSY, 2-1/16"-3K, FLANGE CONN, API 6A, MATERIAL CLASS: AA, TEMP CLASS : U (0 # 250 DEGF), PR : 1 , PSL : 2 |
2 | CHOKE,ADJUST,ASSY 2-9/16"-3000# | Description : CHOKE, ADJUSTABLE ASSEMBLY, 2-9/16" - 3000# WP FLANGE INLET AND OUTLET,WITH 1" MAXIMUM ORIFICE (SCALE TO 64/64), ALL EQUIPMENT SHALL BEMANUFACTURED IN ACCORDANCE WITH API SPEC 6A, LATEST EDITION, PSL-2, PR-1, MONOGRAMMED MATERIAL CLASS : AA, TEMPERATURE CLASS : U (0 - 250 DEG F) |
Wellhead Adjustable Choke Valve 2 9/16" - 3K
2 9/16" - 3K Adjustable Choke Valve API 6A Wellhead Equipment
