Isolated DC Converters Wide input AC/DC switching power supply
we,TOPPOWER can produce:
0.1W-40W DC-DC converters,3W-30W AC-DC converters,(SIP/DIP/SMD)
15W-1200W Enclosed /Open frame/DIN RAIL type AC-DC Switching Power supply,
TOPPOWER quality : ISO9001:2015, IATF16949:2016
The rated output power of TPR/DG-15-XS series is 15~15.6W,input voltage range：90-264VAC,
output voltage : 12V, 24V. High reliability, precision,effificency , ultra-small size, stable output voltage and etc, with short circuit & overload protection, Widely used in telecommunications, industrial control, instrument, data acquisition, signal control , New Energy, Security,and other electronic systems.
AC input ：90VAC-264VAC,DC input:127-370VDC |
Built-in DC OK relay contact
|
Operating temperature：-25℃~70℃
|
Mounting track: TS-35/7.5 or TS-35/15 |
Protection:short circuit,over-load,over-voltage,over-temperature |
Mini width: 32mm |
RoHS complaint |
High reliability,effificency,100% full load burn-in test |
Built-in current limiting circuit capacitors
|
SELECTION GUIDE | ||||||||
Part Number |
Input Volatge |
Output |
Efficiency @25℃, （Typ）% |
|||||
（VAC) |
（VDC) |
Voltage（VDC) |
Pre-set voltage @25℃(V) |
Rated current（A） |
Rated power(W) |
|||
Rated |
Range |
Rated Range |
||||||
TPR/DG-15-12S |
220 |
90-264 |
127-370 |
12 |
12.00-12.20 |
1.25 |
15 |
83 |
TPR/DG-15-24S |
220 |
90-264 |
127-370 |
24 |
24.00-24.20 |
0.65 |
15.6 |
84.5 |
