- Foshan Haohongwei Machinery Equipment Co., Ltd.
-
Foshan, Guangdong, China
- Main products: Aluminum profile cutting machine
ChinaHome > Products > CNC Automatic Cutting Machine > CNC Automatic Cutting Machine
CNC Automatic Cutting Machine
US$ 1 - 100000
/ Set
1 Set(Min. Order)
- Foshan
- T/T L/C
You May Like
Product Details
| Brand Name | Haohong | Place of Origin | China | |
| Model Number | MJ-400B | After-sales Service Provided | Engineers available to service machinery overseas | |
| Condition | New |
Product Description
Parameter：
| Maximum machining range W * L | 200 x 100mm |
| Feeding mode | CNC servo feeding |
| control mode | PLC touch screen |
| Drive feeding mode | Precision ball screw |
| Maximum feeding length (subsection feeding) | 600mm (any length). |
| Machining length accuracy | + 0.1mm |
| Feed speed | 40mm |
| Spindle speed | 3800R/PM |
| Form of pressure | Pneumatic |
| Saw blade motor | 4KW |
| Oil pump motor | 1.5KW |
| Pump motor | 40W |
| servo motor | 750W |
| Saw feed / return speed | 0-3m/2-3m |
| Working pressure | 0.6-0.8mpa |
| working voltage | 380V+ zero line three phase four wire 50HZ |
| Machine weight | 650KG |
| Cooling method of saw blade | Circulating water cooling |
| Saw size | 405 25.4mm x 3.2 x 120T |
| Outline size L * W * H | 1800 x 1200 x 1700mm |
