Model no. :1575 long network multi-cylinder corrugated paper machine basic equipment parameters:
Model 1575 long network multi - cylinder paper machine
Copied varieties of kraft paper, high - strength corrugated base paper
Copy the quantity g over m squared 85 minus 160g over m squared
Clear paper width (mm) 1575mm
The design speed (m/min) is 80-350m/min
Working speed (m/min
Production capacity (t/d) 22--25t/d
Transmission mode variable flow frequency, segment transmission
Model design square box structure, about mobile phone
Sizing method is hanging pulp mode
Applicable to blanket felt
Forming the form of copper wire wound
Structure layout single layer
Applicable power supply (v, HZ) 220, 380 v /50~60HZ
Pneumatic medium compressed air 0.6mpa3 grade industrial compressed air standard
Applicable steam 0.3mpa
Water quality standard PH-7 total alkalinity (mg/L with CaCO3) is no more than 350
The basic area is 120-150m squared
Operator 3 to 5
Applicable raw material waste paper, wood, straw, reed, bagasse, bamboo and so on.
Basic process :(taking waste paper as an example)
Waste paper - pulping - screening - wash pulp pulping -- -- -- -- -- -- the second screening - mixing - mix slurry - sand - online - water - drying - winding - cutting - packaging, warehousing.
Our company can provide the full model series, such as 787, 1092, 1575, 1760, 1880, 2100, 2200, 2400, 2880, 3200, 3600, 4200, garden network, long network, multiple network, and folding paper machine. Applicable paper variety covers the production and processing of all kinds of household paper, medical non-woven cloth, industrial packaging paper, cultural paper and special paper
Our company also has a professional design and installation team of paper and pulping equipment. From the beginning of project planning, we can provide customers with scientific and reasonable project implementation plan and provide all-round and complete technical solutions according to their actual situation.
