Help Center1575mm Corrugated Paper Making Machine Recycle Paper as Raw Material
Related Products
-
Corrugated Paper Making Machinery, Cultural Paper MachineUS$ 200000 - 360000MOQ: 1 Set -
1575type and 2400type Corrugated Paper Making Machinery, Cultural Paper MachineUS$ 200000 - 360000MOQ: 1 Set
-
Africa Best Selling Corrugated Paper Machine From ChinaUS$ 200000 - 360000MOQ: 1 Set
-
Africa Best Selling 1575type Corrugated Paper Machine From ChinaUS$ 200000 - 360000MOQ: 1 Set
-
Africa Best Selling Kraft Paper Making Machine From ChinaUS$ 200000 - 360000MOQ: 1 Set
Machine advantages
Smooth operate,compact appearance,
Reasonable structure,energy saving ,easy operate
Environmental protection
Exquisite craftsmanship and unique design
Technical parameter:
1.Raw material :recycle paper
2.Output paper style:Corrugated paper/ Kraft paper
3.Output paper weight: 80-300 g/m2
4.Net paper width: 1600mm
5.Capacity: 15-20T/D
6.Width of cylinder mould: 1950 mm
7.Rail gauge: 2400 mm
8.Drive way: AC inverter,adj.sp.Processing transmission
Structure of main part:
1.Cylinder section: Φ1500mm×1950mm cylinder mould 2 sets, Φ450mm×1950mm couch roll 2 set, φ400×1950mm reverse roll 1set, rubber shore hardness 38º±2.
2.Press section: Φ500mm×1950mm marble roll 1 set, Φ450mm×1950mm rubber roll 1 set, rubber shore hardness 90º±2.
3.Dryer section:Φ2500mm×1950mm dryer can 2 set,Φ500mm×1950mm touch roll 1 set,rubber shore hardness 90º±2.
4.Drive way: AC inverter speed, section drive.
All pulp making machine:
NO. |
Equipmets |
Qtyset |
1 |
25 m3spherical digester |
2 |
2 |
wood cutting machine |
1 |
3 |
15m conveyor |
1 |
4 |
6m pre-extracting machine |
1 |
5 |
spiral conveyor |
1 |
6 |
Φ600mm high consistency pulp refiner |
1 |
7 |
Φ380mm double disc pulp refiner |
2 |
8 |
Suction box |
2 |
9 |
1m3High consistency hydrapulper |
1 |
10 |
606sander remover ( 3 pcs) |
1 group |
11 |
4 inch pulp Pump |
4 |
12 |
6 inch pulp Pump |
3 |
13 |
Φ700mmThruster |
4 |
14 |
0.9m3Centrifugal screen |
1 |
15 |
8m3cylinder thickener |
1 |
Our factory is a high-tech enterprise which integrates the production and R&D of new-type papermaking machinery and pulping equipment. The main business now is: 787-1092-1575-1760-1880-2100-2400-2640-2880-3200-3600-4000-4750 single-cylinder, double-cylinder, multi-cylinder, long-net papermaking machine, circular net papermaking machine, cow Pulp and paper machine, culture paper machine, Xuan paper machine, carton hanging paper machine, packing corrugated paper machine, and small paper machine for small paper mills and family workshops, small environmental protection paper machine, toilet paper machine, burning paper machine, artillery paper machine, fire paper machine, yellow paper machine, etc. Various types of paper machines.
Our factory has a complete set of pulping equipment: Dutch, Knife-Roller beater, high and low concentration hydraulic pulper, energy-saving pulper, high frequency vibrating screen, vacuum pump, pulp pump, pulp mixer, bamboo roughing mill, propeller, centrifugal screen, desander, processing various rolls and auxiliary equipment (toilet paper rewinder, punching pressure) Flower machine, toilet paper, burning paper cutting machine, etc. Papermaking equipment, calender, rewinder and paper cutter.
Sales manager: hao yingfeng 0086-13603894288
QQ:940746614
Sales manager: hao yingfeng +86-13603894288
Micro letter：13603894288
Email：940746614@qq.com
WhatsApp: 86-13603894288
imo: 86-13603894288
Email: 940746614@qq.com
