Model 1575 -2400 Long Net Paper Machine, Corrugated Paper Machine, Yarn Tube Paper Machine

Model 1575 -2400 long net paper machine, corrugated paper machine, yarn tube paper machine

Model 1575m-2400mm long network multi - cylinder paper machine

Copy of various kraft paper, high-strength corrugated paper and yarn tube paper (g/m2) 85-160g/m2

Clear paper width (mm) 1575mm-2400mm

The design speed (m/min) is 80-500m/min

Working speed (m/min

Production capacity (t/d) 22--60t/d

Transmission mode variable flow frequency, segment transmission

Model design square box structure, about mobile phone

Sizing method is hanging pulp mode

Applicable to blanket felt

Forming the form of copper wire wound

Structure layout single layer

Applicable power supply (v, HZ) 220, 380 v /50~60HZ

Pneumatic medium compressed air 0.6mpa level 3 industrial compressed air standard

Applicable steam 0.3mpa

Water quality standard PH-7 total alkalinity (mg/L with CaCO3) is no more than 350

Basic area of 120-150m2

Operator 3 to 5

Applicable raw material waste paper, wood, straw, reed, bagasse, bamboo and so on.

Basic process :(taking waste paper as an example)

Waste paper - pulping - screening - wash pulp pulping -- -- -- -- -- -- the second screening - mixing - mix slurry - sand - online - water - drying - winding - cutting - packaging, warehousing.

Our company can provide the full model series, such as 787, 1092, 1575, 1760, 1880, 2100, 2400, 2880, 3200, 3600, 4200, garden net, long net, multi-net, and paper folding machine. Applicable paper variety covers the production and processing of all kinds of household paper, corrugated paper, culture paper, kraft paper, yarn tube paper, medical non-woven cloth, industrial packaging paper, culture paper and special paper

Our company also has a professional design and installation team of paper and pulping equipment. From the beginning of project planning, we can provide customers with scientific and reasonable project implementation plan and provide all-round and complete technical solutions according to their actual situation.
