Home > Industrial Equipment & Components > Guide Rail > Steel Guide Rail > TR68 (136RE) America Standard Steel Rail
TR68 (136RE) America Standard Steel Rail
US$ 800 - 850
MOQ: 400 Tons
Key Specifications
Get Latest Price
Brand Name:
BISG
Place of Origin:
China
Model Number:
TR-68 (136RE)
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin port
Delivery Detail:
30 days
Related Products
-
TR45 (90ARA-A) America Standard Steel RailUS$ 800 - 850MOQ: 400 Tons -
TR50 (100RE) America Standard Steel RailUS$ 800 - 850MOQ: 400 Tons
-
MRS 87B (CR 175) America Standard Steel RailUS$ 800 - 850MOQ: 400 Tons
-
BS11-1985 Standard BS90A Steel RailUS$ 800 - 830MOQ: 400 Tons
-
BS100A 900A Railway Steel RailUS$ 800 - 830MOQ: 400 Tons
Brand Name
BISG
Place of Origin
China
Model Number
TR-68 (136RE)
Length
12-36m
Type
Heavy Rail
Weight
67.56 kg/m
Application
Railway Rail
Standard
AISI, ASTM
Grade
900A/1100
Secondary Or Not
Non-secondary
Bolt Hole Diameter
24mm
Head Width
74.6mm
Web Thickness
17.4mm
Bottom Width
152.4mm
Rail Heigth
185.7mm
TR68 (136RE) America standard steel rail
This type of rail is used for America and South America area, it is used in heavy railway line, we can produce it by order, the MOQ should more than 400 tons.
Please leave message to us to ask the details.
| Heavy rail | Height (mm) | Bottom width (mm) | Head width (mm) | Middle thickness (mm) | Length (m) | Weight (kg/m) |
| TR-45 (90 ARA-A) | 142.9 | 130.2 | 65.1 | 14.3 | 12-36 | 44.64 |
| TR-50 (100 RE) | 152.4 | 136.5 | 68.2 | 14.3 | 12-36 | 50.35 |
| TR-57 (115 RE) | 168.3 | 139.7 | 69 | 15.9 | 12-36 | 56.9 |
| TR-68 (136 RE) | 185.7 | 152.4 | 74.6 | 17.4 | 12-36 | 67.56 |
| MRS 87B (CR 175) | 152.4 | 152.4 | 102.4 | 38.1 | 12-36 | 86.8 |
