BS90A 900A Railway Steel Rail

BS90A 900A Railway Steel Rail thumbnail-1
BS90A 900A Railway Steel Rail thumbnail-2
BS90A 900A Railway Steel Rail thumbnail-3
BS90A 900A Railway Steel Rail thumbnail-4
BS90A 900A Railway Steel Rail photo-1
BS90A 900A Railway Steel Rail photo-2
BS90A 900A Railway Steel Rail photo-3
BS90A 900A Railway Steel Rail photo-4
US$ 800 - 830 MOQ: 400 Tons
Key Specifications
Get Latest Price
Brand Name:
BISG
Place of Origin:
China
Model Number:
BS90A (45E1)
Contact Supplier Request Quote Chat Now
Shanghai Yueqi Industrial Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin port
Delivery Detail:
45 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BISG
Place of Origin China
Model Number BS90A (45E1)
Length 12-36m
Type Heavy Rail
Weight 45.1 kg/m
Application Railway Rail
Standard BS
Grade 900A/1100
Secondary Or Not Non-secondary
Bolt Hole Diameter Non
Head Width 66.67mm
Web Thickness 13.89mm
Bottom Width 127mm
Rail Heigth 142.88mm

BS11-1985 BS90A steel rail/ EN13674-4 45E1 900A railway rail



BS 90 A.jpg

Rail Type Rail Height Flange Width Head Width at Top Head Width at Base Head Height Web Thickness Flange Thickness at Edge Flange Thickness at Center Weight (per meter)
RH FW HT HB HH WT FE FM kg
BS 75A rail 128.6 114.3 61.9 63.75 30.5 12.7 8.3 15.48 37.46
BS 90A rail 142.9 127 66.7 68.83 33.5 13.9 9.1 17.07 45.10
BS 100A rail 152.4 133.35 69.85 72.14 35.81 15.08 9.52 16.27 50.18

UIC STEEL RAIL HARDNESS.jpg

Inspecting by Lloyd's-1.jpgInspecting by Lloyd's-4.jpgInspecting by Lloyd's-7.jpgInspecting by Lloyd's-8.jpgInspecting by Lloyd's-9.jpg

chemical components-3.jpgchemical components-1.jpgchemical components-2.jpg


Product Tags: BS90A , 900A railway steel rail , steel rail
