uhmw pe marine fender facing pad, sliding pad
Specification:
material: uhmw pe
thickness: 10mm-300mm
size: as your request
process: mould pressing
color: black, blue, yellow, green, white
appliction: harbour construction, for tug boats, barges and piers
Marine fender pad
UHMW-PE marine fender pad is in more than 5 million unique molecular weight,low coefficient of friction thermoplastics.Extremely high wear resistance(greater than steel) and very low maintenance costs,has widely used in ports fender.Fender pad is easy to install,can be installed to steel frame,conrete,wood and rubber body.
UHMW-PE as the ideal material for low friction, long lasting facings on any fender system or protective panel.
UHMW-PE marine fender pad for steel frame last for longer, generate less friction,lower shear forces,strong tensile strength at yield,tensile strain at yield,tensile strength,enongation at break,impact strength,hardness more than other materials or grades. The most popular colours are black, yellow and blue, and other choices such as green, white, orange, grey and red are available on request.
Property | Unit | Value |
Density | g/cm3 | 0.93-0.96 |
Average molecular weight | g/mol | 3million- 10 million |
Tensile strength (23°C in air) | MPa | 22 |
Breaking strength | MPa | 42 |
Tensile strain at break | % | 600 |
Charpy impact strength (notched) | mJ/mm2 | No break |
Ball indentation hardness | N/mm2 | 42 |
Shore D hardness | -- | 65-70 |
Abrasion | % | 70-80, steel = 100 |
Static Friction Coefficient | -- |
≤0.16 |
Kinetic Friction Coefficient | -- |
≤0.10 |
Water Absorption | -- | NIL |
Elongation at break at 23 degress | % | ≥300 |
Temperature resistance | °C | -269 to +85 |
Melt Temperature | °C | 130-140 |
UHMW-PE marine fender pad Application:
1. SCN Supper Cone Fender
2.Arch Marine fender
3.SCK Cell Fender
4.UE-V Fender
5.MV Fender
6.Parallel Motion Fender
7.Composite Marine Fender
8.CSS Fender
9.Super Circle Fender
10.PMF Parallel Movement Fenders
Certificate
We offer the following products,
UHMW-PE sheets
Ningjin Xinjiang Chemical Co., Ltd. established in 2003
, is one of the largest engineering plastic product manufacturers in China. We are specialized in UHMWPE and HDPE products, like UHMWPE Sheet, UHMWPE fender pads, linings, and it's machined parts.
In order to achieving rapid and sustainable development, we are willing to establish a wide and deep cooperation relation with enterprises both home and abroad.
