Main features:
1 using circular knife cutting, cutting high precision, convenient operation, the cutter can be adjusted;
2 the A and B axis independent winding, convenient handling;
3, shaft adopts automatic tension control, inflatable shaft, orderly and compact rewinding of finished products;
4 feeding frame adopts pneumatic automatic lifting function;
5.Automatic discharging device for waste
6 this machine adopts frequency conversion. Microcomputer automatic control, selection of imported photoelectric deviation device, automatic meter, alarm stop, tension digital display and other advanced features.
Use:
This machine is applicable to the edge of large roll material cutting, slitting, such as printing and packaging plastic membrane type, paper, cloth, and all kinds of paper plastic composite materials such as Lin Mozhi, coated paper, synthetic leather, such as.
Technical parameter:
| model | FQJ-1100A | FQJ-1300A | FQJ-1600A |
| diameter of unwinding | 1400mm | 1400mm | 1400mm |
| width of slitting | 1100mm | 1300mm | 1600mm |
| diameter of rewinding | 1000mm | 1000mm | 1000mm |
| width of rewinding | 30mm | 30mm | 30mm |
| slitting speed | 10-150m/min | 10-150m/min | 10-150m/min |
| slitting accuracy | ±0.3mm | ±0.3mm | ±0.3mm |
| power | 10kw | 11kw | 12kw |
| electric | 380V/50Hz Tri-phase | 380V/50Hz Tri-phase | 380V/50Hz Tri-phase |
| requirement of air pressure source | 5.5kg/cm2×0.5m3/min | 5.5kg/cm2×0.5m3/min | 5.5kg/cm2×0.5m3/min |
| weigh | 2800kg | 3000kg | 3300kg |
| overall dimension | 3800×2500×1800mm | 3800×2800×1800mm | 3800×3100×1800mm |
