Main features:
Sjfm series green laminator, paper plastic composite units (no adhesive composition unit): set discharge, drying, surface treatment, composite, cutting edge, suction side, volume as a whole; the photoelectric error correction, corona treatment, line speed, feed length digital display; automatic constant tensile force, temperature control and advanced technology.
Application:
1.Paper cups : PE coated paper
2.Non woven bags : Non woven fabric + PE
3.Release paper : Release paper + PE
4.Sugar packages : Thin paper + PE
5.Baby diaper : film +PE
6.PP woven sack: sheet roll + PE
Features:
1.PLC man-machine interface centralized control, machine, electricity, gas, integrated design.
2.Car type extrusion machine
3. T- type die head
4. Automatic hydraulic changes filter ( Our Factory patent)
5.Tension controller: you can input diameter and thickness parameter of base material based on replaced material, along with the rotated-loops changing, tension is decreased proportionally to achieve automatic tension control.
6.Speed of compounding roller and rewinding roller synchronize tension automatically.
Main technical parameters:
1.Applicable coating film resin: Coating grade like LDPE 、PP 、EVA、EAA etc .
2.Based material: paper (35~425g/m2 ),non woven, textile, pp woven, jute fabric
3.Max working speed: 100~150m/min
4.Max width of coating film: 1200mm
5.Thickness of coating film: 0.01–0.11mm
6.Inaccuracy thickness of coating film: ±6%
7.Setting range of Auto-tension : 10-200kg/entire width (constant tension)
8.Max extrusion: 200kg/h
9.Compound cooling roller: Φ500×1300mm (can choose)
10. Total power：about 80kw
11.Max rewinding diameter: Φ1300mm
12. Inside diameter of base material: Φ76
13.Machine total weight: about 15000kg
14.Overall dimension:9600mm×8000×3250mm（L×W×H）
15.Machine color: can choose
Q1. What is your terms of packing?
A: Generally, we pack our goods with steel wire fixing , Spray anti-rust oil to prevent rust, and then wrap 5 layers telescopic film covering, and then in wooden case.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF,
Q4. How about your delivery time?
A: Generally, it will take 2 to 3 month after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
